Image preview - the first page of the document

>> Download co documenatation <<

Text preview - extract from the document

ENGINE COOLING SYSTEM

B ENGINE

ENGINE COOLING SYSTEM
SECTION CO CO

E
CONTENTS
PRECAUTIONS ......................................................... 2. RADIATOR (ALUMINUM TYPE) .............................. 13 . F
Precautions for Supplemental Restraint System Disassembly and Assembly ................................... 13 .
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN- PREPARATION .................................................. 13
.
SIONER" ................................................................. 2
. DISASSEMBLY .................................................. 13
. G
Precautions for Liquid Gasket ................................. 2 . ASSEMBLY ........................................................ 14
.
REMOVAL OF LIQUID GASKET SEALING ......... 2 . INSPECTION ..................................................... 16
.
LIQUID GASKET APPLICATION PROCEDURE 2 ..... COOLING FAN ......................................................... 17
.
H
PREPARATION .......................................................... 4
. Removal and Installation ....................................... 17
.
Special Service Tools .............................................. 4. REMOVAL .......................................................... 18
.
Commercial Service Tools ....................................... 4 . INSPECTION AFTER REMOVAL ...................... 18 .
OVERHEATING CAUSE ANALYSIS ......................... 5 . INSTALLATION .................................................. 18
. I
Troubleshooting Chart ............................................. 5 . INSPECTION AFTER INSTALLATION ............... 19 .
COOLING SYSTEM ................................................... 7 . Disassembly and Assembly ................................... 19 .
Cooling Circuit ......................................................... 7
. DISASSEMBLY .................................................. 19
. J
ENGINE COOLANT ................................................... 8 . ASSEMBLY ........................................................ 20
.
Inspection ................................................................ 8
. WATER PUMP ......................................................... 21
.
LEVEL CHECK .................................................... 8 . Removal and Installation ....................................... 21
.
K
LEAK CHECK ...................................................... 8 . REMOVAL .......................................................... 21
.
Changing Engine Coolant ....................................... 8 . INSPECTION AFTER REMOVAL ...................... 22 .
DRAINING ENGINE COOLANT .......................... 8 . INSTALLATION .................................................. 22
.
REFILLING ENGINE COOLANT ......................... 9 . INSPECTION AFTER INSTALLATION ............... 22 . L
FLUSHING COOLING SYSTEM ........................ 10 . THERMOSTAT AND WATER CONTROL VALVE ... 23
RADIATOR ................................................................11
. Removal and Installation ....................................... 23
.
Removal and Installation ........................................11 . REMOVAL .......................................................... 23
. M
REMOVAL ...........................................................11
. INSPECTION AFTER REMOVAL ...................... 24 .
INSTALLATION .................................................. 12 . INSTALLATION .................................................. 24
.
CHECKING RADIATOR CAP ............................. 12 . SERVICE DATA AND SPECIFICATIONS (SDS) ..... 25 .
CHECKING RADIATOR ..................................... 12 . Standard and Limit ................................................. 25
.
CAPACITY .......................................................... 25
.
THERMOSTAT ................................................... 25
.
WATER CONTROL VALVE ................................ 25 .
RADIATOR ......................................................... 25
.
Tightening Torque .................................................. 25
.

Revision: 2004 April CO-1 2002 Q45
PRECAUTIONS

PRECAUTIONS PFP:00001

Precautions for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT
BELT PRE-TENSIONER" EBS003D6

The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SRS and SB section of
this Service Manual.
WARNING:
q To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.
q Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.
q Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions for Liquid Gasket EBS0024Y

REMOVAL OF LIQUID GASKET SEALING
q After removing the mounting bolts and nuts, separate the mating
surface using a seal cutter and remove the liquid gasket sealing.
CAUTION:
Be careful not to damage the mating surfaces.
q In areas where the cutter is difficult to use, use a plastic hammer
to lightly tap the area where the liquid gasket is applied.
CAUTION:
If for some unavoidable reason a tool such as a flat-bladed
screwdriver is used, be careful not to damage the mating sur-
faces.
PBIC0002E

LIQUID GASKET APPLICATION PROCEDURE
1. Using a scraper, remove the old liquid gasket adhering to the
gasket application surface and the mating surface.
q Remove the liquid gasket completely from the groove of the
gasket application surface, mounting bolts, and bolt holes.
2. Wipe the gasket application surface and the mating surface with
white gasoline (lighting and heating use) to remove adhering
moisture, grease and foreign materials.
3. Attach the liquid gasket to the tube presser.
Use Genuine Ultra Grey RTV Silicone Sealant Part No.
999MP-AM003P or equivalent.
PBIC0003E

4. Apply the gasket without breaks to the specified location with the
specified dimensions.
q If there is a groove for the liquid gasket application, apply the
gasket to the groove.

EMA0622D

Revision: 2004 April CO-2 2002 Q45
PRECAUTIONS

q As for the bolt holes, normally apply the gasket inside the
holes. Occasionally, it should be applied outside the holes. A
Make sure to read the text of service manual.
q Within five minutes of gasket application, install the mating
component. CO
q If the liquid gasket protrudes, wipe it off immediately.

q Do not retighten after the installation.

q After 30 minutes or more have passed from the installation, fill C
the engine oil and coolant.
CAUTION: SEM164F
If there are specific instructions in this manual, observe them. D

Revision: 2004 April CO-3 2002 Q45
PREPARATION

PREPARATION PFP:00002

Special Service Tools EBS00256

The actual shapes of Kent-Moore tools may from those of special service tools illustrated here.
Tool number
(Kent-Moore No.) Description
Tool name

WS39930000 Pressing the tube of liquid gasket
(
