Image preview - the first page of the document
EXJ_8J


>> Download EXJ_8J documenatation <<

Text preview - extract from the document
XJ                                                              TURN SIGNAL AND HAZARD WARNING SYSTEMS                        8J - 1



           TURN SIGNAL AND HAZARD WARNING SYSTEMS
                                                             CONTENTS

                                                               page                                                            page

DESCRIPTION AND OPERATION                                                 TURN SIGNAL SWITCH AND HAZARD
  COMBINATION FLASHER . . . . . . . . . . . . . . . . . .            3     WARNING SWITCH . . . . . . . . . . . . . . . . . . . . . 5
  HAZARD WARNING SYSTEM . . . . . . . . . . . . . . .                1   REMOVAL AND INSTALLATION
  TURN SIGNAL CANCELLING CAM . . . . . . . . . . .                   3    COMBINATION FLASHER . . . . . . . . . . . . . . . . . . 5
  TURN SIGNAL SWITCH AND HAZARD                                           TURN SIGNAL SWITCH AND HAZARD
   WARNING SWITCH . . . . . . . . . . . . . . . . . . . . .          2     WARNING SWITCH . . . . . . . . . . . . . . . . . . . . . 6
  TURN SIGNAL SYSTEM . . . . . . . . . . . . . . . . . . .           1
DIAGNOSIS AND TESTING
  TURN SIGNAL AND HAZARD WARNING
   SYSTEMS . . . . . . . . . . . . . . . . . . . . . . . . . . . .   4

DESCRIPTION AND OPERATION                                                lamp and rear tail/stop/turn signal lamp to flash on
                                                                         and off. If the exterior lamps are turned off, the front
TURN SIGNAL SYSTEM                                                       park/turn signal lamp and the front side marker
                                                                         lamp will flash in unison. If the exterior lamps are
DESCRIPTION                                                              turned on, the front park/turn signal lamp and the
  A turn signal system is standard factory-installed                     front side marker lamp will flash alternately.
safety equipment on this model. The turn signal sys-                       See the owner's manual in the vehicle glove box for
tem uses ignition switched battery current, and will                     more information on the features, use and operation
operate only when the ignition switch is in the On or                    of the turn signal system.
Accessory positions. The turn signal system includes
the following components:                                                HAZARD WARNING SYSTEM
