Image preview - the first page of the document
>> Download exj_23 documenatation <<
Text preview - extract from the document
XJ BODY 23 - 1
BODY
TABLE OF CONTENTS
page page
DESCRIPTION AND OPERATION . . . . . . . . . . . . . . 1 STATIONARY GLASS. . . . . . . . . . . . . . . . . . . . . . . . 6
SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . 3 SEATS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
PAINT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 BODY COMPONENT SERVICE . . . . . . . . . . . . . . . 21
DESCRIPTION AND OPERATION
TABLE OF CONTENTS
page
DESCRIPTION AND OPERATION
BODY COMPONENTS . . . . . . . . . . . . . . . . . . . . . . 1
DESCRIPTION AND OPERATION elements. Windshields are also used to retain some
airbags in position during deployment. Urethane
BODY COMPONENTS bonded glass is difficult to salvage during removal.
The urethane bonding is difficult to cut or clean from
PAINT any surface. Before removing the glass, check the
availability of replacement components.
DESCRIPTION
The original equipment finish is a multi-step pro- SEATS
cess that involves cleaning, electrodeposition (e-coat),
DESCRIPTION
base coat, and clear coat steps. Additionally, selected
areas of the vehicle may be coated with an anti-chip Seat modules are made up of a seat frame, seat
finish. cushion, seat back cushion, a covering material, and
the electrical components used for power operation, if
OPERATION equipped. Some seat systems also contain seat belt
On most vehicles a two-stage paint application components and supplemental restraint systems.
(base coat/clear coat) is used. Color that is applied to
OPERATION
primer is called base coat. The clear coat protects the
base coat from ultraviolet light and provides a dura- Seat assemblies transport the occupants in comfort
ble high-gloss finish. and safety. Seat assemblies also help position occu-
pants correctly in the event of airbag deployment.
STATIONARY GLASS Seat cushions, coverings, and electrical components
are serviceable. Refer to the appropriate group in
DESCRIPTION this manual.
Windshields and selected stationary glass are
structural members of the vehicle. The windshield EXTERIOR COMPONENTS
glass is bonded to the windshield frame with ure-
DESCRIPTION
thane adhesive.
Exterior sheet metal components make up the
OPERATION exterior of the vehicle. Some exterior metal systems
Windshields are made of two pieces of glass with a are welded assemblies, such as doors and hoods.
plastic inner layer. Windshields and other stationary Some exterior trim items are made of composite.
glass protect the occupants from the effects of the
23 - 2 BODY XJ
DESCRIPTION AND OPERATION (Continued)
OPERATION component systems are adjustable as a system. Trim
The exterior is finished in various metal stampings components made of composite are stamped with the
and composite moldings. These assemblies give the type of material used. DaimlerChrysler uses various
vehicle a finished appearance and protect the occu- fasteners to retain trim items. At times, it is not pos-
pants from the elements. Some components are part sible to remove trim items without damaging the fas-
of the energy absorbing system used to protect the tener. If it is not possible to remove an item without
occupants in collisions. The exterior sheet metal is damaging a component, cut or break the fasteners
repairable and adjustable for fit and finish. Welded and use new ones when installing the component.
XJ BODY 23 - 3
SAFETY PRECAUTIONS
TABLE OF CONTENTS
page
SERVICE PROCEDURES
SAFETY PRECAUTIONS AND WARNINGS . . . . . . 3
SERVICE PROCEDURES Do not use abrasive chemicals or compounds on
painted surfaces. Damage to finish can result.
SAFETY PRECAUTIONS AND WARNINGS Do not use harsh alkaline based cleaning sol-
vents on painted or upholstered surfaces. Damage
DESCRIPTION to finish or color can result.
Do not hammer or pound on plastic trim panel
WARNING: USE A OSHA APPROVED BREATHING when servicing interior trim. Plastic panels can
FILTER WHEN SPRAYING PAINT OR SOLVENTS IN break.
A CONFINED AREA. PERSONAL INJURY CAN
RESULT. DaimlerChrysler Corporation uses many different
AVOID PROLONGED SKIN CONTACT WITH types of push-in fasteners to secure the interior and
PETROLEUM OR ALCOHOL ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
