Image preview - the first page of the document



>> Download exj_8ca documenatation <<

Text preview - extract from the document

XJ                                                                                                   CHARGING SYSTEM                8C - 1



                                               CHARGING SYSTEM
                                                    TABLE OF CONTENTS

                                                               page                                                                   page

REMOVAL AND INSTALLATION                                                 SPECIFICATIONS
 GENERATOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1    SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . 2

REMOVAL AND INSTALLATION
GENERATOR
WARNING: DISCONNECT NEGATIVE CABLE FROM
BATTERY BEFORE REMOVING BATTERY OUTPUT
WIRE FROM GENERATOR. FAILURE TO DO SO
CAN RESULT IN INJURY.


CAUTION: Never force a belt over a pulley rim
using a screwdriver. The synthetic fiber of the belt
can be damaged.


CAUTION: When installing a serpentine accessory
drive belt, the belt MUST be routed correctly. The
water pump will be rotating in the wrong direction if
the belt is installed incorrectly, causing the engine
to overheat. Refer to belt routing label in engine
compartment, or refer to Belt Schematics in Group
7, Cooling System.

   (1) Disconnect negative battery cable.                                                Fig. 1 Generator Electrical
   (2) Remove generator drive belt. Refer to Group 7,                    1
