Image preview - the first page of the document
>> Download bt documenatation <<
Text preview - extract from the document
BODY & TRIM
SECTION BT
CONTENTS
PRECAUTIONS ...............................................................2 TRUNK ROOM TRIM .....................................................31
Service Notice..............................................................2 Removal and Installation ...........................................31
Supplemental Restraint System (SRS) AIR EXTERIOR .....................................................................32
BAG and SEAT BELT PRE-TENSIONER...............2 Removal and Installation ...........................................32
CLIP AND FASTENER....................................................3 FRONT SEAT ................................................................38
Description ...................................................................3 Removal and Installation ...........................................38
BODY FRONT END.........................................................5 POWER SEAT .........................................................39
Removal and Installation .............................................5 HEATED SEAT ........................................................40
FRONT BUMPER ASSEMBLY ....................................5 Active Head Restraint................................................40
BODY REAR END AND OPENER..................................8 OPERATION OUTLINE ............................................40
Removal and Installation .............................................8 REAR SEAT...................................................................41
REAR BUMPER ASSEMBLY ......................................8 Removal and Installation ...........................................41
DOOR.............................................................................11 SUNROOF......................................................................42
Adjustment .................................................................11 Adjustment .................................................................42
STRIKER ADJUSTMENT ..........................................11 Removal.....................................................................42
Front Door Glass .......................................................12 Trouble Diagnoses.....................................................46
FRONT DOOR GLASS AND REGULATOR ................12 DIAGNOSTIC TABLE................................................46
Front Door Limit Switch Reset (Driver side only)......13 WIND DEFLECTOR .................................................46
RESET CONDITIONS ..............................................13 ADJUSTMENT .........................................................47
RESET PROCEDURES ............................................13 DRAIN HOSES ........................................................48
Rear Door Glass........................................................14 WEATHERSTRIP .....................................................48
REAR DOOR GLASS AND REGULATOR ..................14 LINK AND WIRE ASSEMBLY ....................................49
Front Door Lock.........................................................16 WINDSHIELD AND WINDOWS ....................................50
BELL CRANK ADJUSTMENT ....................................16 Removal and Installation ...........................................50
OUTSIDE HANDLE ROD ADJUSTMENT ...................16 REMOVAL ...............................................................50
REMOVAL ...............................................................17 INSTALLATION........................................................50
Rear Door Lock .........................................................18 WINDSHIELD ..........................................................51
OUTSIDE HANDLE ROD ADJUSTMENT ...................18 DOOR MIRROR .............................................................52
REMOVAL ...............................................................19 Removal and Installation ...........................................52
INSTRUMENT PANEL ASSEMBLY .............................20 REAR VIEW MIRROR ...................................................53
Removal and Installation ...........................................20 Removal and Installation ...........................................53
SIDE AND FLOOR TRIM...............................................24 REMOVAL ...............................................................53
Removal and Installation ...........................................24 INSTALLATION........................................................53
DOOR TRIM ...................................................................27 BODY (ALIGNMENT) ....................................................54
Removal and Installation ...........................................27 Alignment ...................................................................54
ROOF TRIM ...................................................................29 ENGINE COMPARTMENT ........................................55
Removal and Installation ...........................................29 UNDERBODY ..........................................................57
PRECAUTIONS
Service Notice
Service Notice NFBT0001
+ When removing or installing various parts, place a cloth or padding onto the vehicle body to prevent
scratches.
+ Handle trim, molding, instruments, grille, etc. carefully during removing or installing. Be careful not to soil
or damage them.
+ Apply sealing compound where necessary when installing parts.
+ When applying sealing compound, be careful that the sealing compound does not protrude from parts.
+ When replacing any metal parts (for example body outer panel, members, etc.), be sure to take rust pre-
vention measures.
Supplemental Restraint System (SRS) "AIR
BAG" and "SEAT BELT PRE-TENSIONER" NFBT0002
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER" used along with
a seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain types of
collision. The SRS system composition which is available to NISSAN MODEL A33 is as follows (The compo-
sition varies according to the destination and optional equipment.):
+ For a frontal collision
The Supplemental Restraint System consists of driver air bag module (located in the center of the steer-
ing wheel), front passenger air bag module (located on the instrument panel on passenger side), seat belt
pre-tensioners, a diagnosis sensor unit, warning lamp, wiring harness and spiral cable.
+ For a side collision
The Supplemental Restraint System consists of front side air bag module (located in the outer side of front
seat), satellite sensor, diagnosis sensor unit (one of components of air bags for a frontal collision), wiring
harness, warning lamp (one of components of air bags for a frontal collision).
Information necessary to service the system safely is included in the RS section of this Service Manual.
WARNING:
+ To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance should be per-
formed by an authorized NISSAN dealer.
+ Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the RS section.
+ Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. Spiral cable and wiring harnesses covered with yellow insulation tape either just
before the harness connectors or for the complete harness are related to the SRS.
BT-2
CLIP AND FASTENER
Description
Description NFBT0003
+ Clips and fasteners in BT section correspond to the following numbers and symbols.
+ Replace any clips and/or fasteners which are damaged during removal or installation.
Symbol No. Shapes Removal & Installation
C101
SBF302H
SBF367BA
C103
SBT095
SBF423H
C205
MBT080A SBF638CA
C206
MBF519B
MBF520B
CE103
SBF104B
SBF147B
BT-3
CLIP AND FASTENER
Description (Cont'd)
Symbol No. Shapes Removal & Installation
CF110
SBF648B
SBF649B
CF118
SBF151D SBF259G
CR103
SBF768B
SBF770B
BT-4
BODY FRONT END
Removal and Installation
Removal and Installation NFBT0004
+ When removing or installing hood, place a cloth or other padding on hood. This prevents vehicle body from
being scratched.
+ Bumper fascia is made of plastic. Do not use excessive force and be sure to keep oil away from it.
+ Hood adjustment: Adjust at hinge portion.
+ Hood lock adjustment: After adjusting, check hood lock control operation. Apply a coat of grease to hood
locks engaging mechanism.
+ Hood opener: Do not attempt to bend cable forcibly. Doing so increases effort required to unlock hood.
WARNING:
+ Be careful not to scratch hood stay when installing hood. A scratched stay may cause gas leak-
age.
+ The contents of the hood stay are under pressure. Do not take apart, puncture, apply heat or allow
fire near it.
FRONT BUMPER ASSEMBLY NFBT0004S01
1. Remove clips securing engine undercover to bumper fascia.
2. Remove clips and bolts securing left and right sides of front fender protectors.
3. Remove screws and clips securing left and right sides of front fender protectors.
4. Remove clips and screws securing left and right sides of front fender protectors in wheelhouse.
5. Remove screws securing left and right front fenders to bumper fascia.
6. Remove clips securing bumper fascia.
7. Extract bumper fascia assembly, then disconnect fog lamp assembly harness connectors.
8. Remove energy absorber.
9. Remove bolts and hook securing headlamp assembly, then disconnect harness connectors.
10. Remove nuts securing bumper reinforcement to left and right bumper stays.
11. Extract bumper reinforcement.
12. Remove bolts and nuts securing front bumper bracket.
13. Remove bolts and nut securing bumper stays, then remove the bumper stays.
Fog lamp assembly
14. Remove bolt securing fog lamp assembly.
15. Extract fog lamp assembly.
SBT896
BT-5
BODY FRONT END
Removal and Installation (Cont'd)
SBT897
BT-6
BODY FRONT END
Removal and Installation (Cont'd)
SBT898
BT-7
BODY REAR END AND OPENER
Removal and Installation
Removal and Installation NFBT0005
+ When removing or installing trunk lid, place a cloth or other padding on trunk lid. This prevents vehicle
body from being scratched.
+ Bumper fascia is made of plastic. Do not use excessive force and be sure to keep oil away from it.
+ Trunk lid adjustment: Adjust at hinge-trunk lid portion for proper trunk lid fit.
+ Trunk lid lock system adjustment: Adjust striker so that it is in the center of the lock. After adjustment, check
trunk lid lock operation.
+ After installation, make sure that trunk lid and fuel filler lid open smoothly.
5 For Wiring Diagram, refer to EL-207, "TRUNK LID AND FUEL FILLER LID OPENER".
REAR BUMPER ASSEMBLY NFBT0005S01
1. Remove screws securing left and right rear fenders to bumper fascia.
2. Remove screws securing left and right rear fenders to bumper fascia lower side.
3. Remove clips securing bumper fascia.
4. Remove trunk room trim. Refer to "TRUNK ROOM TRIM" for details, BT-31.
5. Working from inside trunk, remove nuts securing rear combination lamp assembly, then disconnect har-
ness connectors.
6. Working from inside trunk, remove jack then remove nuts securing jack bracket.
7. Working from inside trunk, remove bolts securing left and right rear fenders to bumper fascia.
8. Working from inside trunk, remove nuts securing left and right rear fenders to bumper fascia.
9. Remove clips securing left and right rear bumper bracket assembly to bumper fascia.
10. Extract rear bumper fascia assembly after removing the clamps securing it.
11. Remove energy absorber.
12. Remove nuts securing bumper reinforcement to left and right bumper stays.
13. Extract bumper reinforcement.
14. Remove nuts securing bumper stays, then remove the bumper stays.
SBT864
BT-8
BODY REAR END AND OPENER
Removal and Installation (Cont'd)
SBT899
BT-9
BODY REAR END AND OPENER
Removal and Installation (Cont'd)
SBT866-A
BT-10
DOOR
Adjustment
Adjustment NFBT0006
SBT771-A
STRIKER ADJUSTMENT NFBT0006S01
Adjust striker so that it is parallel with advancing direction of door
lock.
SBT772-A
BT-11
DOOR
Front Door Glass
Front Door Glass =NFBT0007
+ Make sure that door glass is positioned in glass run groove.
+ Make sure that there is no abnormality when door glass is
raised or lowered.
FRONT DOOR GLASS AND REGULATOR NFBT0007S01
SBT773-A
+ For removal of front door trim, refer to "DOOR TRIM", BT-27.
+ For removal of door mirror, refer to "DOOR MIRROR", BT-52.
+ For removal of door outside molding, refer to "EXTERIOR",
BT-32.
+ Remove sealing screen.
1. Using power window main switch, raise or lower door glass
until carrier plate securing bolts are visible.
2. Remove bolts securing carrier plate.
SBT774-A
BT-12
DOOR
Front Door Glass (Cont'd)
3. Hold door glass with both hands. While raising rear end of door
glass, remove door glass from sash and away from outside the
door.
SBT775
4. Disconnect regulator assembly connector.
5. Remove bolts securing regulator assembly and guide rail, then
remove regulator assembly and guide rail.
SBT776-B
Inspection NFBT0007S0101
Check regulator assembly for the following parts. Replace faulty
parts with new ones.
+ Wire for wear
+ Regulator for deformation
+ Sliding parts for lubrication
SBT777
Front Door Limit Switch Reset (Driver side
only) NFBT0008
RESET CONDITIONS NFBT0008S01
After each of the following operations are performed, reset the limit
switch (with built-in motor).
+ Regulator removal and installation
+ Removal of motor from regulator
+ Operation of regulator as a single unit
+ Door glass removal and installation
+ Glass run removal and installation
RESET PROCEDURES NFBT0008S02
After installing parts, proceed as follows:
1. Close the door window completely.
2. Press the reset switch and open the door window completely.
3. Release the reset switch. After making sure the reset switch
has returned to the original position, close the door window
completely.
4. The limit switch is now reset.
CAUTION:
Be sure to manually open or close the door window. (Do not
SBT778
use the automatic open-close procedures.)
BT-13
DOOR
Rear Door Glass
Rear Door Glass NFBT0009
+ Make sure that door glass is positioned in glass run groove.
+ Make sure that there is no abnormality when door glass is
raised or lowered.
REAR DOOR GLASS AND REGULATOR NFBT0009S01
SBT779-A
+ For removal of rear door trim, refer to "DOOR TRIM", BT-27.
+ For removal of door outside molding, refer to "EXTERIOR",
BT-32.
+ Remove sealing screen.
1. Using power window main switch, raise or lower door glass
until carrier plate securing bolts are visible.
2. Remove bolts securing carrier plate.
SBT780-A
BT-14
DOOR
Rear Door Glass (Cont'd)
3. Remove partition sash at glass run.
4. Remove bolts and screw securing partition sash.
SBT781
5. Hold door glass with both hands. While raising rear end of door
glass, remove door glass from sash and away from inside the
door.
SBT782
6. Disconnect regulator assembly connector.
7. Remove bolts securing regulator assembly and guide rail, then
remove regulator assembly and guide rail.
SBT783-A
8. Remove partition glass.
SBT784
Inspection NFBT0009S0101
Check regulator assembly for the following parts. Replace faulty
parts with new ones.
+ Wire for wear
+ Regulator for deformation
+ Sliding parts for lubrication
SBT785
BT-15
DOOR
Front Door Lock
Front Door Lock NFBT0010
SBT786-A
+ For removal of front door trim, refer to "DOOR TRIM", BT-27.
+ Remove sealing screen.
BELL CRANK ADJUSTMENT NFBT0010S01
CAUTION:
Before adjusting bell crank, make sure that rod is installed to
inside handle.
After installing door lock and inside handle, set them in the lock
position. Using a flat-bladed screwdriver, expand rod holder.
Remove rod free play at joining area and set rod in position.
After adjusting bell crank adjustments have been made, operate
door lock knob, door lock switch and door key to make sure that
they lock and unlock properly.
SBT787
OUTSIDE HANDLE ROD ADJUSTMENT NFBT0010S02
Rotate rod holder so that rod-to-holder clearance is adjusted as
shown in the figure at left.
CAUTION:
Make sure that rod-to-holder clearance is not "0" mm (0 in),
and that rod is not held pressed.
SBT788
BT-16
DOOR
Front Door Lock (Cont'd)
REMOVAL NFBT0010S03
+ For removal of front door trim, refer to "DOOR TRIM", BT-27.
+ Remove sealing screen.
+ For removal of front door glass, refer to "Front Door Glass",
BT-12.
1. Remove lower rear sash (unitized with glass run) securing
bolts. Remove lower rear sash from door panel and away from
door lock.
SBT789-A
2. Remove inside handle escutcheon A.
3. Remove screw securing inside handle.
4. Detach bell crank at lock knob joining area.
5. Detach inside handle rod on the door lock assembly side.
6. Slide inside handle backward and remove inside handle.
7. Remove rod from inside handle.
SBT790
8. Detach key lock rod and outside handle rod at joining area (on
the outside handle side).
9. Disconnect door lock actuator connector.
10. Remove screws securing door lock assembly, then remove
door lock assembly.
11. Remove bolts securing outside handle, then remove outside
handle assembly.
SBT791-A
BT-17
DOOR
Rear Door Lock
Rear Door Lock =NFBT0011
SBT792-A
+ For removal of rear door trim, refer to "DOOR TRIM", BT-27.
+ Remove sealing screen.
OUTSIDE HANDLE ROD ADJUSTMENT NFBT0011S01
Rotate rod holder so that rod-to-holder clearance is adjusted as
shown in the figure at left.
CAUTION:
Make sure that rod-to-holder clearance is not "0" mm (0 in),
and that rod is not held pressed.
SBT788
BT-18
DOOR
Rear Door Lock (Cont'd)
REMOVAL =NFBT0011S02
+ For removal of rear door trim, refer to "DOOR TRIM", BT-27.
+ Remove sealing screen.
+ For removal of rear door glass, refer to "Rear Door Glass",
BT-14.
1. Remove inside handle escutcheon A.
2. Remove screw securing inside handle.
3. Detach inside handle rod on the door lock assembly side.
SBT793
4. Detach lock knob rod (on the door lock assembly side).
5. Using a flat-bladed screwdriver, expand rod holder. Remove
rod from rod holder.
6. Slide inside handle backward and remove inside handle.
7. Remove rod from inside handle.
8. Disconnect door lock actuator connector.
9. Remove screws securing door lock assembly, then remove
door lock assembly.
10. Remove bolts securing outside handle, then remove outside
handle.
SBT794
BT-19
INSTRUMENT PANEL ASSEMBLY
Removal and Installation
Removal and Installation NFBT0012
CAUTION:
+ Disconnect ground terminal from battery in advance.
+ Disconnect air bag system line in advance.
+ Never tamper with or force air bag lid open, as this may adversely affect air bag performance.
+ Be careful not to scratch pad and other parts.
BT-20
INSTRUMENT PANEL ASSEMBLY
Removal and Installation (Cont'd)
SBT956
*1 RS-17 *3 ST-10 *4 RS-19
*2 BT-24
BT-21
INSTRUMENT PANEL ASSEMBLY
Removal and Installation (Cont'd)
SBT900
BT-22
INSTRUMENT PANEL ASSEMBLY
Removal and Installation (Cont'd)
SBT948
BT-23
SIDE AND FLOOR TRIM
Removal and Installation
Removal and Installation NFBT0013
CAUTION:
+ Wrap the tip of flat-bladed screwdriver with a cloth when removing metal clips from garnishes.
+ When removing or installing body side welts, do not allow butyl seal to come in contact with pil-
lar garnish.
1. Remove front and rear seats. Refer to "FRONT SEAT" and "REAR SEAT" for details, BT-38 and BT-41.
2. Remove front and rear seat belts. Refer to RS- 5 and RS-7, "Front Seat Belt" and "Rear Seat Belt" for
details.
3. Remove front and rear outer kicking plates.
4. Remove front and rear inner kicking plates.
5. Remove dash side lower finisher.
6. Remove front and rear body side welts.
7. Remove front pillar garnishes.
8. Remove center pillar upper garnishes.
9. Remove center pillar lower garnishes.
10. Remove rear pillar garnishes.
11. Remove high-mounted stop lamp. (Model without rear air spoiler)
12. Remove seatback center finisher.
13. Remove seatback side finishers.
14. Remove rear parcel shelf finisher.
15. Remove instrument lower covers.
16. Remove accelerator pedal stopper.
17. Remove carpet hook.
18. Remove floor carpet.
SBT837
BT-24
SIDE AND FLOOR TRIM
Removal and Installation (Cont'd)
SBT949
BT-25
SIDE AND FLOOR TRIM
Removal and Installation (Cont'd)
SBT950
BT-26
DOOR TRIM
Removal and Installation
Removal and Installation NFBT0014
Front door finisher
1. Remove inside handle escutcheon.
2. Remove power window switch finisher, then disconnect the connectors.
3. Remove screw securing pull handle, and then remove pull handle.
4. Remove mask securing front door finisher.
5. Remove screw securing front door finisher.
6. Remove clips securing front door finisher.
7. Lift out front door finisher. Disconnect harness connectors.
Rear door finisher
8. Remove inside handle escutcheon.
9. Remove power window switch finisher, then disconnect the connector.
10. Remove screw securing pull handle, and then remove pull handle.
11. Remove clips securing rear door finisher.
12. Lift out rear door finisher.
SBT951
BT-27
DOOR TRIM
Removal and Installation (Cont'd)
SBT050A
BT-28
ROOF TRIM
Removal and Installation
Removal and Installation NFBT0015
CAUTION:
When removing or installing body side welts, do not allow butyl seal to come in contact with pillar
garnish and headlining.
1. Remove rear seats. Refer to "REAR SEAT" for details, BT-41.
2. Remove shoulder anchor bolts. Refer to RS-5, "Front Seat Belt" for details.
3. Remove front pillar garnishes, center pillar upper garnishes and rear pillar garnishes. Refer to "SIDE AND
FLOOR TRIM" for details, BT-24.
4. Remove steering wheel. Refer to RS-17, "Driver Air Bag Module and Spiral Cable" for details.
5. Push back the front seat back.
6. Insert a removal tool wrapped in a clean cloth between the right-hand side of the map light and the sun-
roof finisher, then disconnect connectors.
7. Remove roof console.
8. Remove sun visors.
9. Remove assist grips.
10. Remove interior lamp assembly, then disconnect connectors.
11. Remove metal clip securing headlining, then remove headlining from vehicle through front passenger side.
SBT051A
BT-29
ROOF TRIM
Removal and Installation (Cont'd)
SBT952
BT-30
TRUNK ROOM TRIM
Removal and Installation
Removal and Installation NFBT0016
SBT953
BT-31
EXTERIOR
Removal and Installation
Removal and Installation NFBT0017
SBT874
BT-32
EXTERIOR
Removal and Installation (Cont'd)
SBT806
BT-33
EXTERIOR
Removal and Installation (Cont'd)
SBT807
BT-34
EXTERIOR
Removal and Installation (Cont'd)
SBT808
BT-35
EXTERIOR
Removal and Installation (Cont'd)
SBT954
BT-36
EXTERIOR
Removal and Installation (Cont'd)
SBT052A
BT-37
FRONT SEAT
Removal and Installation
Removal and Installation NFBT0018
+ When removing or installing the seat trim, carefully handle it to keep dirt out and avoid damage.
5 For Wiring Diagram, refer to EL-209, "POWER SEAT" for details.
CAUTION:
+ Before removing the front seat, turn the ignition switch off, disconnect both battery cables and wait
at least 3 minutes.
+ When checking the power seat circuit for continuity using a circuit tester, do not confuse its con-
nector with the side air bag module connector. Such an error may cause the air bag to deploy.
+ Do not drop, tilt, or bump the side air bag module installed in the seat. Always handle it with care.
BT-38
FRONT SEAT
Removal and Installation (Cont'd)
POWER SEAT NFBT0018S01
SBT877
BT-39
FRONT SEAT
Removal and Installation (Cont'd)
HEATED SEAT NFBT0018S03
+ When handling seat, be extremely careful not to scratch heating unit.
+ To replace heating unit, seat trim and pad should be separated.
+ Do not use any organic solvent, such as thinner, benzene, alcohol, gasoline, etc. to clean trims.
5 For Wiring Diagram, refer to EL-213, "HEATED SEAT" for details.
Active Head Restraint NFBT0032
The active head restraint system is designed so that the headrest
instantaneously moves towards the front upper direction by utiliz-
ing the force at the seatback during a rear-end collision.
As a result, the occupant's head is protected from being
overextended, reducing the chance for neck injury as much as
possible.
Seat with active head restraint have the labels shown in figures at
left.
SBT887
OPERATION OUTLINE NFBT0032S01
When the seatback receives a sharp backward force during a rear-
end collision, the input plate moves with the link rotating center as
a pivot. The headrest will then move towards the front upper direc-
tion with the center of the sliding roller as a pivot.
As the backward force on the seat back is eliminated, spring ten-
sion returns the headrest to its original position.
SBT888
BT-40
REAR SEAT
Removal and Installation
Removal and Installation NFBT0019
SBT812
BT-41
SUNROOF
Adjustment
Adjustment NFBT0020
Install motor & limit SW assembly and sunroof rail assembly in the following sequence:
1. Arrange equal lengths of link and wire assemblies on both sides of sunroof opening.
2. Connect sunroof connector to sunroof switch and positive (+) power supply.
3. Set lid assembly to fully closed position by operating OPEN switch and TILT switch.
4. Fit outer side of lid assembly to the surface of roof on body outer panel.
5. Remove motor, and keep OPEN switch pressed until motor pinion gear reaches the end of its rotating
range.
6. Install motor.
7. Check that motor drive gear fits properly in wires.
8. Press TILT-UP switch to check lid assembly for normal tilting.
9. Check sunroof lid assembly for normal operations (tilt-up, tilt-down, open, and close).
SBF920F
Removal NFBT0021
+ After any adjustment, check sunroof operation and lid align-
ment.
+ Handle finisher plate and glass lid with care so not to cause
damage.
+ It is desirable for easy installation to mark each point before
removal.
CAUTION:
Always work with a helper.
BT-42
SUNROOF
Removal (Cont'd)
SBT838
*1 BT-29 *2 EL-202
BT-43
SUNROOF
Removal (Cont'd)
SBT878
BT-44
SUNROOF
Removal (Cont'd)
Record the number of shims placed between glass lid assem-
bly and link and wire assembly. Remove securing nuts and glass
lid assembly.
SBT826
Remove screws from left and right sides of each wind deflector
holder. Extract pawls through rail holes, then remove left and right
sides of wind deflector holder. Remove screws from front end of
sunroof unit. Extract pawls through frame holes, then remove wind
deflector from frame assembly.
SBT827
CAUTION:
+ Before removing sunroof motor, make sure that sunroof is
fully closed.
+ After removing sunroof motor, never attempt to rotate
sunroof motor as a single unit.
SBT828
Remove shade stoppers (2 points) from rear end of sunroof
frame assembly. Remove sun shade from rear end of sunroof
frame assembly.
SBT829
BT-45
SUNROOF
Trouble Diagnoses
Trouble Diagnoses =NFBT0022
DIAGNOSTIC TABLE NFBT0022S01
NOTE:
For diagnosing electric problem, refer to "ELECTRIC SUNROOF"
in EL section.
Check items (Components)
Link and wire
Wind deflector Adjustment Drain hoses Weatherstrip
assembly
Reference page BT-46 BT-47 BT-48 BT-48 BT-49
Excessive wind
1 2 3
noise
Water leaks 1 2 3
Symptom
Sunroof rattles 1 4 2 3
Excessive opera-
1 2 3
tion noise
The numbers in this table mean checking order.
WIND DEFLECTOR NFBT0022S02
1. Open lid.
2. Check visually for proper installation.
3. Check to ensure a proper amount of petroleum jelly has been
applied to wind deflector connection points; apply if necessary.
SBT331
4. Check that wind deflector is properly retracted by hand. If it is
not, remove and visually check condition. (Refer to removal
procedures, BT-42.) If wind deflector is damaged, replace with
new one. If wind deflector is not damaged, re-install properly.
SBT332
BT-46
SUNROOF
Trouble Diagnoses (Cont'd)
ADJUSTMENT NFBT0022S03
SBT482-A
If any gap or height difference between glass lid and roof is found,
check glass lid fit and adjust as follows:
Gap Adjustment NFBT0022S0301
1. Open shade assembly.
2. Tilt glass lid up then remove side trim.
3. Loosen glass lid securing nuts (3 each on left and right sides),
then tilt glass lid down.
4. Adjust glass lid from outside of vehicle so it resembles "A-A"
as shown in the figure above.
5. Tilt glass lid up and down until it is adjusted to "B-B" as shown
in the figure above.
6. After adjusting glass lid, tilt glass lid up and tighten nuts.
7. Tilt glass lid up and down several times to check that it moves
smoothly.
Height Difference Adjustment NFBT0022S0302
1. Tilt glass lid up and down.
2. Check height difference between roof panel and glass lid to
see if it is as "A-A" as shown in the figure above.
3. If necessary, adjust it by using one of following procedures.
+ Adjust by adding or removing adjustment shim(s) between
glass lid and link assembly.
+ If glass lid protrudes above roof panel, add shim(s) or plain
washer(s) at sunroof mounting bracket or stud bolt locations to
adjust sunroof installation as required.
BT-47
SUNROOF
Trouble Diagnoses (Cont'd)
DRAIN HOSES NFBT0022S04
SBT879
1. Remove headlining to access drain hose connections. (Refer
to "ROOF TRIM", BT-29, for detail.)
2. Check visually for proper connections, damage or deteriora-
tion. (The figure shows only the front side.)
SBT333
3. If leakage occurs around luggage room, remove luggage room
side trim and check connecting area. Check for proper
connection, damage or tear.
4. Remove drain hoses and check visually for any damage,
cracks, or deterioration.
5. Pour water into drain hoses and find damaged portion.
+ If any damaged portion is found at each step, replace the
damaged part.
SBT820
WEATHERSTRIP NFBT0022S05
+ In the case of leakage around glass lid, close glass lid and pour
water over glass lid to find damaged or gap portion.
1. Remove glass lid assembly. (Refer to removal procedures,
BT-42, for details.)
2. Visually check weatherstrip for proper installation. If a gap
exists between glass lid and weatherstrip, check for sufficient
amount of butyl seal. If required, remove weatherstrip and
apply butyl seal.
Refer to "EXTERIOR", BT-32, for details.
BT-48
SUNROOF
Trouble Diagnoses (Cont'd)
3. Check weatherstrip visually for any damage, deterioration, or
flattening.
+ If any damage is found, replace weatherstrip.
CAUTION:
Do not remove weatherstrip except when replacing, or filling
up butyl seal.
LINK AND WIRE ASSEMBLY NFBT0022S06
NOTE:
Before replacing a suspect part, carefully ensure it is the source of
noise being experienced.
1. Check link to determine if coating film has peeled off to such
an extent that substrate is visible. Check also to determine if
link is the source of noise. If it is, replace it.
2. Visually check to determine if a sufficient amount of petroleum
jelly has been applied to wire or rail groove. If not, add petro-
leum jelly as required.
3. Check wire for any damage or deterioration. If any damage is
found, remove rear guide (refer to removal procedures, BT-42,
for details), then replace wire.
BT-49
WINDSHIELD AND WINDOWS
Removal and Installation
Removal and Installation NFBT0023
REMOVAL NFBT0023S01
After removing moldings, remove glass using piano wire or power
cutting tool and an inflatable pump bag.
WARNING:
When cutting the glass from the vehicle, always wear safety
glasses and heavy gloves to help prevent glass splinters from
entering your eyes or cutting your hands.
CAUTION:
+ Be careful not to scratch the glass when removing.
SBF034BA
+ Do not set or stand the glass on its edge. Small chips may
develop into cracks.
INSTALLATION NFBT0023S02
+ Use a genuine Nissan Urethane Adhesive Kit or equivalent
and follow the instructions furnished with it.
+ While the urethane adhesive is curing, open a door win-
dow. This will prevent the glass from being forced out by
passenger compartment air pressure when a door is
closed.
+ The molding must be installed securely so that it is in
position and leaves no gap.
+ Inform the customer that the vehicle should remain sta-
SBT472 tionary until the urethane adhesive has completely cured
(preferably 24 hours). Curing time varies with temperature
and humidity.
WARNING:
+ Keep heat and open flames away as primers and adhesive
are flammable.
+ The materials contained in the kit are harmful if
swallowed, and may irritate skin and eyes. Avoid contact
with the skin and eyes.
+ Use in an open, well ventilated location. Avoid breathing
the vapors. They can be harmful if inhaled. If affected by
vapor inhalation, immediately move to an area with fresh
SBT473 air.
+ Driving the vehicle before the urethane adhesive has com-
pletely cured may affect the performance of the wind-
shield in case of an accident.
CAUTION:
+ Do not use an adhesive which is past its usable term.
Shelf life of this product is limited to six months after the
date of manufacture. Carefully adhere to the expiration or
manufacture date printed on the box.
+ Keep primers and adhesive in a cool, dry place. Ideally,
they should be stored in a refrigerator.
BT-50
WINDSHIELD AND WINDOWS
Removal and Installation (Cont'd)
+ Do not leave primers or adhesive cartridge unattended
with their caps open or off.
+ The vehicle should not be driven for at least 24 hours or
until the urethane adhesive has completely cured. Curing
time varies depending on temperature and humidities. The
curing time will increase under higher temperatures and
lower humidities.
WINDSHIELD NFBT0023S03
SBT823
Repairing Water Leaks for Windshield NFBT0023S0301
Leaks can be repaired without removing and reinstalling glass.
If water is leaking between the urethane adhesive material and
body or glass, determine the extent of leakage. This can be
done by applying water to the windshield area while pushing
glass outward.
To stop the leak, apply primer (if necessary) and then urethane
adhesive to the leak point.
BT-51
DOOR MIRROR
Removal and Installation
Removal and Installation NFBT0024
CAUTION:
Be careful not to scratch door rearview mirror body.
5 For Wiring Diagram, refer to EL-204, "DOOR MIRROR" for details.
1. Remove door trim. Refer to "DOOR TRIM" for details, BT-27.
2. Remove inner cover front corner of door.
3. Disconnect door mirror harness connector.
4. Remove door mirror harness clips.
5. Remove bolts securing door mirror assembly.
6. Remove the mirror glass. Do not insert screwdriver too far.
SBT813
BT-52
REAR VIEW MIRROR
Removal and Installation
Removal and Installation NFBT0025
REMOVAL NFBT0025S01
SBT880
INSTALLATION NFBT0025S02
1. Install mirror base as follows:
a. Determine mirror base position on windshield by measuring
from top of windshield to top of mirror base as shown in the
figure.
b. Mark location on outside of windshield with wax pencil or
equivalent.
c. Clean attaching point on inside of windshield with an alcohol-
saturated panel towel.
d. Sand bonding surface of mirror base with sandpaper (No. 320
SBT822 or No. 360).
e. Clean bonding surface of mirror base with an alcohol-saturated
paper towel.
f. Apply Loctite Adhesive 11067-2 or equivalent to bonding sur-
face of mirror base.
g. Install mirror base at premarked position and press mirror base
against glass for 30 to 60 seconds.
h. After five minutes, wipe off excess adhesive with an alcohol-
moistened paper towel.
2. Install rearview mirror.
BT-53
BODY (ALIGNMENT)
Alignment
Alignment NFBT0026
+ All dimensions indicated in figures are actual ones.
+ When using a tracking gauge, adjust both pointers to equal length. Then check the pointers and gauge
itself to make sure there is no free play.
+ When a measuring tape is used, check to be sure there is no elongation, twisting or bending.
+ Measurements should be taken at the center of the mounting holes.
+ An asterisk (*) following the value at the measuring point indicates that the measuring point on the other
side is symmetrically the same value.
+ The coordinates of the measurement points are the distances measured from the standard line of "X", "Y"
and "Z".
SBF874GB
BT-54
BODY (ALIGNMENT)
Alignment (Cont'd)
ENGINE COMPARTMENT NFBT0026S01
Measurement NFBT0026S0101
SBT881
BT-55
BODY (ALIGNMENT)
Alignment (Cont'd)
Measurement Points NFBT0026S0102
SBT882
BT-56
BODY (ALIGNMENT)
Alignment (Cont'd)
UNDERBODY NFBT0026S02
Measurement NFBT0026S0201
SBT883
BT-57
BODY (ALIGNMENT)
Alignment (Cont'd)
Measurement Points NFBT0026S0202
SBT884
BT-58
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
