Image preview - the first page of the document
cl


>> Download cl documenatation <<

Text preview - extract from the document
                                                                                                                                               CLUTCH


                                                                                                    SECTION                       CL
                                                                CONTENTS
PRECAUTIONS ...............................................................2          CLUTCH DAMPER ........................................................13
  Precautions ..................................................................2       Components...............................................................13
PREPARATION ...............................................................3            Inspection...................................................................13
  Special Service Tools ..................................................3           PIPING ...........................................................................14
  Commercial Service Tools ...........................................3                 Removal.....................................................................14
NOISE, VIBRATION AND HARSHNESS (NVH)                                                    Installation..................................................................14
TROUBLESHOOTING .....................................................4                CLUTCH RELEASE MECHANISM ...............................15
  NVH Troubleshooting Chart.........................................4                   Components...............................................................15
     CLUTCH ...................................................................4        Removal.....................................................................15
CLUTCH SYSTEM...........................................................5               Inspection...................................................................15
  Components.................................................................5          Installation..................................................................15
  Inspection and Adjustment ..........................................6               CLUTCH DISC, CLUTCH COVER AND
     ADJUSTING CLUTCH PEDAL ....................................6                     FLYWHEEL....................................................................17
     AIR BLEEDING PROCEDURE ....................................6                       Components...............................................................17
CLUTCH MASTER CYLINDER.......................................8                          Inspection and Adjustment ........................................17
  Components.................................................................8             CLUTCH DISC.........................................................17
  Removal.......................................................................9          CLUTCH COVER .....................................................18
  Installation....................................................................9        FLYWHEEL .............................................................18
  Disassembly.................................................................9         Installation..................................................................18
  Inspection.....................................................................9    SERVICE DATA AND SPECIFICATIONS (SDS) .........19
  Assembly ...................................................................10        Clutch Control System...............................................19
OPERATING CYLINDER...............................................11                     Clutch Master Cylinder ..............................................19
  Components...............................................................11           Clutch Operating Cylinder .........................................19
  Removal.....................................................................11        Clutch Damper...........................................................19
  Disassembly...............................................................11          Clutch Disc.................................................................19
  Inspection...................................................................11       Clutch Cover ..............................................................19
  Assembly ...................................................................12        Clutch Pedal ..............................................................20
  Installation..................................................................12
                         PRECAUTIONS
Precautions

                        Precautions                                                NFCL0001
                        +   Recommended fluid is brake fluid "DOT 3" or "DOT 4".
                            Refer to MA-13, "Fluid and Lubricant".
                        + Never reuse drained brake fluid.
                        + Be careful not to splash brake fluid on painted areas.
                        + When removing and installing clutch piping, use Tool.
                        + Use new brake fluid to clean or wash all parts of master
                            cylinder, operating cylinder and clutch damper.
                        + Never use mineral oils such as gasoline or kerosene. It will
                            ruin the rubber parts of the hydraulic system.
              SBR686C
                        WARNING:
                        After cleaning clutch disc, wipe it with a dust collector. Do not
                        use compressed air.




                                CL-2
                                     PREPARATION
                                                                                    Special Service Tools

                                     Special Service Tools                                         NFCL0002


Tool number
                       Description
Tool name

ST20630000                                           Installing clutch cover and clutch disc
Clutch aligning bar                                  a: 15.8 mm (0.622 in) dia.
                                                     b: 22.9 mm (0.902 in) dia.
                                                     c: 45.0 mm (1.772 in)



                       NT405

ST20050240                                           Adjusting unevenness of diaphragm spring of
Diaphragm spring                                     clutch cover
adjusting wrench                                     a: 150 mm (5.91 in)
                                                     b: 25 mm (0.98 in)


                       NT404


                                     Commercial Service Tools                                      NFCL0003


Tool name              Description

1 Flare nut crowfoot                                 Removing and installing clutch piping
2 Torque wrench                                      a: 10 mm (0.39 in)




                       NT360




                                          CL-3
                                                                                                                                                                                                                                                                                                                                                                                  NVH




                                               Symptom
                                                                                                                                                                                                                     CLUTCH




                                                                                                                                                                                 Reference page




                                                                                                                                     (Possible cause)




       gage
                                                                                                                                     SUSPECTED PARTS




                                Clutch slips
                                                   Clutch noisy
                                                                  Clutch pedal spongy
                                                                                        Clutch grabs/chatters




       Clutch does not disen-
             1
                                1
                                                                                                                CLUTCH PEDAL (Free play out of adjustment)                      CL-6




             2
                                                                  1
                                                                                                                CLUTCH LINE (Air in line)                                       CL-6




             3
                                                                  2
                                                                                                                MASTER CYLINDER PISTON CUP (Damaged)                            CL-8




             4
                                                                  2
                                                                                                                OPERATING CYLINDER PISTON CUP (Damaged)                        CL-11
                                                                                                                                                                                                                              tion. If necessary, repair or replace these parts.




                                                                                        1
                                                                                                                ENGINE MOUNTING (Loose)                      Refer to EM-56, "Removal and Installation".




                                                   1
                                                                                                                RELEASE BEARING (Worn, dirty or damaged)                       CL-15




CL-4
             5
                                                                                                                CLUTCH DISC (Out of true)                                      CL-17




             5
                                                                                        2
                                                                                                                CLUTCH DISC (Runout is excessive)                              CL-17




             5
                                                                                                                CLUTCH DISC (Lining broken)                                    CL-17




             5
                                                                                                                CLUTCH DISC (Dirty or burned)                                  CL-17




             5
                                2
                                                                                        2
                                                                                                                CLUTCH DISC (Oily)                                             CL-17
                                                                                                                                                                                                                                                                                                                                                      NVH Troubleshooting Chart




                                2
                                                                                        2
                                                                                                                CLUTCH DISC (Worn out)                                         CL-17




                                                                                        2
                                                                                                                CLUTCH DISC (Hardened)                                         CL-17




             5
                                                                                                                CLUTCH DISC (Lack of spline grease)                            CL-17




             6
                                3
                                                                                                                DIAPHRAGM SPRING (Damaged)                                     CL-18




             6
                                                                                        2
                                                                                                                DIAPHRAGM SPRING (Out of tip alignment)                        CL-18
                                                                                                                                                                                                                                                                                                                                                                                        NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING




             7
                                4
                                                                                                                PRESSURE PLATE (Distortion)                                    CL-18




                                5
                                                                                                                FLYWHEEL (Distortion)                                          CL-18
                                                                                                                                                                                                           NFCL0004S0101
                                                                                                                                                                                                                                                                                                                                             NFCL0004S01
                                                                                                                                                                                                                                                                                                                                                                                                                                               NFCL0004




                                                                                                                                                                                                                              Use the chart below to help you find the cause of the symptom. The numbers indicate the order of the inspec-
                                    CLUTCH SYSTEM
                                                                                 Components

                                    Components                                           NFCL0005




                                                                                       SCL832-A


1.   Pedal bracket            9.    Withdrawal lever   16.   ASCD clutch switch
2.   Clutch master cylinder   10.   Release bearing    17.   Washer
3.   Pedal stopper bolt       11.   Clutch hose        18.   Clutch hose connector
4.   Fulcrum pin              12.   Clutch cover       19.   Bushing
5.   Pin                      13.   Clutch disc        20.   Stopper rubber
6.   Clutch pedal             14.   Clevis pin         21.   Clutch damper
7.   Operating cylinder       15.   Assist spring      22.   Clutch piping connector
8.   Air bleeder valve




                                              CL-5
                                       CLUTCH SYSTEM
Inspection and Adjustment

                                       Inspection and Adjustment                                       NFCL0006
                                       ADJUSTING CLUTCH PEDAL                                       NFCL0006S01
                                       Pedal Height                                                NFCL0006S0101
                                       1.   Adjust pedal height with ASCD clutch switch or pedal stopper
                                            bolt.
                                                Pedal height "H":
                                                  LHD model:
                                                    179.5 - 189.5 mm (7.07 - 7.46 in)
                                                  RHD model:
                                                    193.5 - 203.5 mm (7.62 - 8.01 in)




                            SCL715-A

                                       2.   Adjust pedal free play with master cylinder push rod. Then
                                            tighten lock nut.
                                                Pedal free play "A":
                                                  9 - 16 mm (0.35 - 0.63 in)
                                       +    Push or step on clutch pedal until resistance is felt, and check
                                            the distance the pedal moves.




                             SCL702

                                       AIR BLEEDING PROCEDURE                                       NFCL0006S02
                                       VQ20DE (LHD) Model                                          NFCL0006S0201
                                       1.   Bleed air from clutch damper according to the following proce-
                                            dure.
                                       +    Carefully monitor fluid level at master cylinder during air
                                            bleeding operation.
                                       +    Be careful not to splash brake fluid on painted areas; it
                                            may cause paint damage. If brake fluid is splashed on
                                            painted areas, wash it away with water immediately.
                                       a.   Top up reservoir of master cylinder with recommended brake
                                            fluid.
                                       b.   Connect a transparent vinyl tube to air bleeder valve.
                                       c.   Slowly depress clutch pedal to its full stroke and release it
                                            completely. Repeat this operation several times at 2 to 3 sec-
                                            ond intervals.
                                       d.   Holding clutch pedal depressed, open air bleeder valve to
                                            release air.
                                       e.   Close air bleeder valve.
                                       f.   Release clutch pedal and wait at least 5 seconds.
                                       g.   Repeat steps c through f above until brake fluid flows from air
                                            bleeder valve without air bubbles.
                             SCL833


                                                CL-6
CLUTCH SYSTEM
                                      Inspection and Adjustment (Cont'd)
2.   Bleed air from clutch operating cylinder according to the above
     same procedure.
3.   Repeat the above air bleeding procedures 1 and 2 several
     times.
        Tightening torque of air bleeder valve:
           Refer to "Components", CL-5.
VQ20DE (RHD) Model                                            NFCL0006S0202
1.   Bleed air from operating cylinder according to the following
     procedure.
+    Carefully monitor fluid level at master cylinder during air
     bleeding operation.
+    Be careful not to splash brake fluid on painted areas; it
     may cause paint damage. If brake fluid is splashed on
     painted areas, wash it away with water immediately.
a.   Top up reservoir of master cylinder with recommended brake fluid.
b.   Connect a transparent vinyl tube to air bleeder valve.
c.   Slowly depress clutch pedal to its full stroke and release it
     completely. Repeat this operation several times at 2 to 3 sec-
     ond intervals.
d.   Holding clutch pedal depressed, open air bleeder valve to
     release air.
e.   Close air bleeder valve.
f.   Release clutch pedal and wait at least 5 seconds.
g.   Repeat steps c through f above until brake fluid flows from air
     bleeder valve without air bubbles.
2.   Repeat the above air bleeding procedure several times.
         Tightening torque of air bleeder valve:
           Refer to "Components", CL-5.
VQ30DE Model                                                  NFCL0006S0203
1.   Bleed air from clutch piping connector according to the follow-
     ing procedure.
+    Carefully monitor fluid level at master cylinder during air
     bleeding operation.
+    Be careful not to splash brake fluid on painted areas; it
     may cause paint damage. If brake fluid is splashed on
     painted areas, wash it away with water immediately.
a.   Top up reservoir of master cylinder with recommended brake
     fluid.
b.   Connect a transparent vinyl tube to air bleeder valve.
c.   Slowly depress clutch pedal to its full stroke and release it
     completely. Repeat this operation several times at 2 to 3 sec-
     ond intervals.
d.   Holding clutch pedal depressed, open air bleeder valve to
     release air.
e.   Close air bleeder valve.
f.   Release clutch pedal and wait at least 5 seconds.
g.   Repeat steps c through f above until brake fluid flows from air
     bleeder valve without air bubbles.
2.   Bleed air from clutch operating cylinder according to the above
     same procedure.
3.   Repeat the above air bleeding procedures 1 and 2 several
     times.
         Tightening torque of air bleeder valve:
            Refer to "Components", CL-5.

         CL-7
             CLUTCH MASTER CYLINDER
Components

                 Components              NFCL0007




                                       SCL850




                                      SCL743-C




                      CL-8
CLUTCH MASTER CYLINDER
                                                                      Removal

         Removal                                                        NFCL0008
         1. Drain brake fluid.
         CAUTION:
         Be careful not to splash brake fluid on painted areas; it may
         cause paint damage. If brake fluid is splashed on painted
         areas, wash it away with water immediately.
         2. Remove clutch tube using a flare nut wrench.
         3. Remove snap pin between clutch pedal and push rod, and
             remove clevis pin.
         4. Unscrew master cylinder assembly mounting nuts and remove
             master cylinder assembly from vehicle.
         Installation                                                   NFCL0009
         1.   Connect clutch tube to master cylinder assembly, and hand-
              tighten flare nut.
         2.   Install master cylinder assembly to vehicle, and tighten mount-
              ing nuts to the specified torque.
                      : 8 - 11 N



◦ Jabse Service Manual Search 2024 ◦ Jabse PravopisonTap.bg ◦ Other service manual resources online : FixyaeServiceinfo
