Image preview - the first page of the document
>> Download su documenatation <<
Text preview - extract from the document
FRONT & REAR SUSPENSION
SECTION SU
CONTENTS
FRONT SUSPENSION ....................................................2 WHEELARCH HEIGHT (UNLADEN*) .........................17
Precautions ..................................................................2 WHEEL RUNOUT ....................................................17
PRECAUTIONS .........................................................2 REAR SUSPENSION.....................................................18
Preparation ..................................................................2 Precautions ................................................................18
SPECIAL SERVICE TOOLS ........................................2 PRECAUTIONS .......................................................18
COMMERCIAL SERVICE TOOLS ................................2 Preparation ................................................................18
Noise, Vibration and Harshness (NVH) COMMERCIAL SERVICE TOOLS ..............................18
Troubleshooting ...........................................................4 Noise, Vibration and Harshness (NVH)
NVH TROUBLESHOOTING CHART ............................4 Troubleshooting .........................................................18
Components.................................................................5 Components...............................................................19
On-vehicle Service.......................................................6 On-vehicle Service.....................................................20
FRONT SUSPENSION PARTS ...................................6 REAR SUSPENSION PARTS ...................................20
FRONT WHEEL ALIGNMENT .....................................6 REAR WHEEL ALIGNMENT .....................................20
Coil Spring and Shock Absorber ...............................10 Removal and Installation ...........................................23
COMPONENTS .......................................................10 REMOVAL ...............................................................24
REMOVAL AND INSTALLATION ...............................11 INSTALLATION........................................................24
DISASSEMBLY ........................................................11 Coil Spring and Shock Absorber ...............................25
INSPECTION ...........................................................11 REMOVAL AND INSTALLATION ...............................25
ASSEMBLY .............................................................12 DISASSEMBLY ........................................................25
Stabilizer Bar .............................................................12 INSPECTION ...........................................................25
REMOVAL AND INSTALLATION ...............................12 ASSEMBLY .............................................................26
Transverse Link and Lower Ball Joint .......................13 Torsion Beam, Lateral Link and Control Rod ............26
REMOVAL AND INSTALLATION ...............................13 DISASSEMBLY ........................................................26
INSPECTION ...........................................................14 INSPECTION ...........................................................26
Service Data and Specifications (SDS).....................15 ASSEMBLY .............................................................27
GENERAL SPECIFICATIONS (FRONT) .....................15 Service Data and Specifications (SDS).....................28
FRONT WHEEL ALIGNMENT (UNLADEN*1) .............16 GENERAL SPECIFICATIONS (REAR) .......................28
LOWER BALL JOINT ...............................................16 REAR WHEEL ALIGNMENT (UNLADEN*) .................28
FRONT SUSPENSION
Precautions
Precautions
PRECAUTIONS NFSU0001
+ When installing rubber parts, final tightening must be car-
ried out under unladen condition* with tires on ground.
Oil will shorten the life of rubber bushes. Be sure to wipe
off any spilled oil.
*: Fuel, radiator coolant and engine oil full. Spare tire, jack,
hand tools and mats in designated positions.
+ After installing removed suspension parts, check wheel
alignment and adjust if necessary.
SBR686C + Use flare nut wrench when removing or installing brake
tubes.
+ Always torque brake lines when installing.
+ Lock nuts are unreusable parts; always use new ones.
When replacing, do not wipe the oil off the new lock nut
before tightening.
Preparation
SPECIAL SERVICE TOOLS NFSU0002
Tool number
Description
Tool name
HT72520000 Removing tie-rod outer end and lower ball joint
Ball joint remover
NT146
COMMERCIAL SERVICE TOOLS NFSU0003
Tool name Description
Attachment Wheel align- Measure wheel alignment
ment a: Screw M24 x 1.5 pitch
b: 35 mm (1.38 in) dia.
c: 65 mm (2.56 in) dia.
d: 56 mm (2.20 in)
e: 12 mm (0.47 in)
NT148
1 Flare nut crowfoot Removing and installing each brake piping
2 Torque wrench a: 10 mm (0.39 in)
NT360
SU-2
FRONT SUSPENSION
Preparation (Cont'd)
Tool name Description
Spring compressor Removing and installing coil spring
NT717
SU-3
FRONT SUSPENSION
Noise,
Noise, Vibration and Harshness (NVH)
Troubleshooting =NFSU0004
NVH TROUBLESHOOTING CHART NFSU0004S01
Use the chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.
Refer to ROAD WHEEL
Refer to SUSPENSION
Refer to TIRES
in this chart.
in this chart.
in this chart.
SU-10, 23
SU-11, 25
SU-5, 19
SU-12
SU-6
SU-6
BR-6
AX-3
AX-3
ST-5
--
--
--
--
--
--
--
--
--
Reference page
Bushing or mounting deterioration
Improper installation, looseness
Shock absorber deformation,
Incorrect wheel alignment
Deformation or damage
Suspension looseness
Incorrect air pressure
damage or deflection
Stabilizer bar fatigue
Possible Cause
and SUSPECTED
Parts interference
Incorrect tire size
Uneven tire wear
ROAD WHEEL
PARTS
DRIVE SHAFT
SUSPENSION
Non-uniformity
Spring fatigue
Out-of-round
STEERING
Imbalance
BRAKES
TIRES
AXLE
