Image preview - the first page of the document
>> Download LC documenatation <<Text preview - extract from the document ENGINE LUBRICATION & GI
COOLING SYSTEMS
MA
SECTION LC EM
LC
EC
CONTENTS FE
PRECAUTIONS AND PREPARATION............................2 Removal ..................................................................9
CL
Supplemental Restraint System (SRS) Thermostat.................................................................10
``AIR BAG'' ...................................................................2 Radiator .....................................................................11
Liquid Gasket Application Procedure ..........................2 Cooling Fan (Crankshaft driven) ...............................12 MT
Special Service Tools ..................................................3 Inspection ..............................................................12
ENGINE LUBRICATION SYSTEM ..................................4 Refilling engine coolant ....................................12
Lubrication Circuit ........................................................4 Radiator (Aluminum type)..........................................13 AT
Oil Pressure Check......................................................5 Inspection ..............................................................13
Oil Pump ......................................................................5 Overheating Cause Analysis .....................................14
ENGINE COOLING SYSTEM..........................................7 SERVICE DATA AND SPECIFICATIONS (SDS) ..........15 TF
Cooling Circuit .............................................................7 Engine Lubrication System........................................15
System Check..............................................................7 Engine Cooling System .............................................15
Water Pump .................................................................9 PD
FA
RA
BR
ST
RS
BT
HA
EL
IDX
PRECAUTIONS AND PREPARATION
Supplemental Restraint System (SRS)
``AIR BAG''
The Supplemental Restraint System ``AIR BAG'', used along with a seat belt, helps to reduce the risk or
severity of injury to the driver and front passenger in a frontal collision. The Supplemental Restraint System
consists of air bag modules (located in the center of the steering wheel and in the instrument panel on the
passenger side), a diagnosis sensor unit, a crash zone sensor (4WD models), warning lamp, wiring harness
and spiral cable.
The vehicle is equipped with a passenger air bag deactivation switch. Because no rear seat exists where a
rear-facing child restraint can be placed, the switch is designed to turn off the passenger air bag so that a
rear-facing child restraint can be used in the front passenger seat. The switch is located in the center of the
instrument panel, near the ashtray. When the switch is turned to the ON position, the passenger air bag is
enabled and could inflate in a frontal collision. When the switch is turned to the OFF position, the passenger
air bag is disabled and will not inflate in a frontal collision. A passenger air bag OFF indicator on the instru-
ment panel lights up when the passenger air bag is switched OFF. The driver air bag always remains enabled
and is not affected by the passenger air bag deactivation switch.
Information necessary to service the system safely is included in the RS section of this Service Manual.
WARNING:
q To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance should be per-
formed by an authorized NISSAN dealer.
q Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system.
q Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses are covered with yellow insulation either just before the
harness connectors or on the complete harness, for easy identification.
q The vehicle is equipped with a passenger air bag deactivation switch which can be operated by
the customer. When the passenger air bag is switched OFF, the passenger air bag is disabled and
will not inflate in a frontal collision. When the passenger air bag is switched ON, the passenger air
bag is enabled and could inflate in a frontal collision. After SRS maintenance or repair, make sure
the passenger air bag deactivation switch is in the same position (ON or OFF) as when the vehicle
arrived for service.
Liquid Gasket Application Procedure
a. Use a scraper to remove all traces of old liquid gasket from
mating surfaces and grooves. Also, completely clean any oil
from these areas.
b. Apply a continuous bead of liquid gasket to mating surfaces.
(Use Genuine RTV Silicone Sealant Part No. 999 MP-A7007
or equivalent.)
q For oil pan, be sure liquid gasket diameter is 3.5 to 4.5 mm
(0.138 to 0.177 in).
q For areas except oil pan, be sure liquid gasket diameter is
SEM164F 2.0 to 3.0 mm (0.079 to 0.118 in).
c. Apply liquid gasket around the inner side of bolt holes (unless
otherwise specified).
d. Assembly should be done within 5 minutes after coating.
e. Wait at least 30 minutes before refilling engine oil and engine
coolant.
AEM080
LC-2
