Image preview - the first page of the document
>> Download MA documenatation <<
Text preview - extract from the document
L MAINTENANCE
A
B
SECTION
MAINTENANCE C
D
E
CONTENTS
PRECAUTIONS ......................................................... 3
. INSTALLATION .................................................. 20 . F
Precautions for Supplemental Restraint System Checking EVAP Vapor Lines ................................. 20 .
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN- CHASSIS AND BODY MAINTENANCE .................. 21 .
SIONER" ................................................................. 3
. Changing the In-cabin Microfilter ........................... 21 . G
PREPARATION .......................................................... 4
. Checking the Exhaust System ............................... 22 .
Special Service Tools .............................................. 4
. Checking the Automatic Transmission Fluid (ATF) 22 ...
Commercial Service Tool ........................................ 4 . Changing the Automatic Transmission Fluid (ATF) 24 ...
H
GENERAL MAINTENANCE ...................................... 5 . Checking the Manual Transmission Fluid (MTF) ... 24
General Maintenance .............................................. 5. OIL LEAKAGE AND OIL LEVEL ........................ 24 .
PERIODIC MAINTENANCE ...................................... 7 . Changing the Manual Transmission Fluid (MTF) ... 25
Introduction of Periodic Maintenance ...................... 7 . DRAINING .......................................................... 25
. I
Schedule 1 .............................................................. 7
. FILLING .............................................................. 25
.
EMISSION CONTROL SYSTEM MAINTE- Checking Transfer Fluid ........................................ 25 .
NANCE ................................................................. 7
. FLUID LEAKAGE AND FLUID LEVEL ............... 25 . J
CHASSIS AND BODY MAINTENANCE .............. 8 . Changing Transfer Fluid ........................................ 25 .
Schedule 2 .............................................................. 9
. DRAINING .......................................................... 25
.
EMISSION CONTROL SYSTEM MAINTE- FILLING .............................................................. 26
.
K
NANCE ................................................................. 9
. Checking Propeller Shaft ....................................... 26 .
CHASSIS AND BODY MAINTENANCE ............ 10 . Checking Front Final Drive Oil ............................... 26 .
RECOMMENDED FLUIDS AND LUBRICANTS ......11 . OIL LEAKAGE AND OIL LEVEL ........................ 26 .
Fluids and Lubricants .............................................11
. Changing Front Final Drive Oil .............................. 26 . MA
SAE Viscosity Number .......................................... 12 . DRAINING .......................................................... 26
.
GASOLINE ENGINE OIL ................................... 12 . FILLING .............................................................. 27
.
ANTI-FREEZE COOLANT MIXTURE RATIO .... 12 . Checking Rear Final Drive Oil ............................... 27 . M
ENGINE MAINTENANCE ........................................ 13 . OIL LEAKAGE AND OIL LEVEL ........................ 27 .
Checking Drive Belts ............................................. 13
. Changing Rear Final Drive Oil ............................... 27 .
DRIVE BELT TENSION ..................................... 13 . DRAINING .......................................................... 27
.
Changing Engine Coolant ..................................... 13 . FILLING .............................................................. 28
.
DRAINING ENGINE COOLANT ........................ 13 . Balancing Wheels .................................................. 28 .
REFILLING ENGINE COOLANT ....................... 14 . WHEEL BALANCE ADJUSTMENT .................... 28 .
FLUSHING COOLING SYSTEM ........................ 16 . Tire Rotation .......................................................... 30
.
Checking Fuel Lines .............................................. 16
. Checking Brake Fluid Level and Leaks ................. 30 .
Changing Fuel Filter .............................................. 16
. Checking Brake Lines and Cables ........................ 30 .
Changing Engine Air Cleaner Filter ....................... 17 . Checking Disc Brake ............................................. 31 .
VISCOUS PAPER TYPE .................................... 17 . ROTOR ............................................................... 31
.
Changing Engine Oil ............................................. 17. CALIPER ............................................................ 31
.
Changing Oil Filter ................................................ 18
. PAD .................................................................... 31
.
Changing Spark Plugs (Platinum - Tipped Type) ... 19 Checking Steering Gear and Linkage .................... 31 .
REMOVAL .......................................................... 19
. STEERING GEAR .............................................. 31 .
INSPECTION AFTER REMOVAL ...................... 19 . STEERING LINKAGE ........................................ 31 .
Revision: February 2006 MA-1 2005 Xterra
Checking Power Steering Fluid and Lines ............. 32 . PARTS ................................................................32
.
CHECKING FLUID LEVEL ................................. 32. FRONT DRIVE SHAFT .......................................32 .
CHECKING LINES ............................................. 32
. Lubricating Locks, Hinges and Hood Latches ........33 .
Checking Axle and Suspension Parts .................... 32. Checking Seat Belts, Buckles, Retractors, Anchors
FRONT AND REAR AXLE AND SUSPENSION and Adjusters .........................................................34
.
Revision: February 2006 MA-2 2005 Xterra
PRECAUTIONS
PRECAUTIONS PFP:00001
A
Precautions for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT
BELT PRE-TENSIONER" ELS001HG
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along B
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front C
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING: D
G To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer. E
G Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section. F
G Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
G
H
I
J
K
MA
M
Revision: February 2006 MA-3 2005 Xterra
PREPARATION
PREPARATION PFP:00002
Special Service Tools ELS001HH
The actual shapes of the Kent-Moore tools may differ from those of the special service tools illustrated here.
Tool number Description
(Kent-Moore No.)
Tool name
KV10115801 Removing and installing oil filter
(J-38956) a: 64.3 mm (2.531 in)
Oil filter cap wrench
NT375
KV991J0010 Checking concentration of ethylene glycol in
(J-23688) engine coolant
Engine coolant refractometer
WBIA0539E
Commercial Service Tool ELS001HI
(Kent-Moore No.) Description
Tool name
KV991J0070 Filling cooling system
(J-45695)
Coolant refill tool
LMA053
Power tool Loosening bolts and nuts
PBIC0190E
Revision: February 2006 MA-4 2005 Xterra
GENERAL MAINTENANCE
GENERAL MAINTENANCE PFP:00000
A
General Maintenance ELS001HJ
General maintenance includes those items which should be checked during the normal day-to-day operation
of the vehicle. They are essential if the vehicle is to continue operating properly. The owner can perform these B
checks and inspections or have their NISSAN dealers perform them.
OUTSIDE THE VEHICLE
The maintenance items listed here should be performed from time to time, unless otherwise specified. C
Item Reference page
Tires Check the pressure with a gauge at least once a month and always prior to a
long distance trip. Adjust to the specified pressure if necessary. Check carefully -- D
for damage, cuts or excessive wear.
Wheel lug nuts When checking the tires, make sure no nuts are missing, and check for any
WT-7, "Rotation"
loose nuts. Tighten if necessary.
E
Windshield Clean the windshield on a regular basis. Check the windshield at least every six
months for cracks or other damage. Repair as necessary.
Tire rotation Tires should be rotated every 12,000 km (7,500 miles). WT-7, "Rotation" F
Wheel alignment and If the vehicle pulls to either side while driving on a straight and level road, or if
WT-6, "Balancing
balance you detect uneven or abnormal tire wear, there may be a need for wheel align-
Wheels", FSU-6, "Front
ment. If the steering wheel or seat vibrates at normal highway speeds, wheel
Wheel Alignment" G
balancing may be needed.
Windshield wiper Check for cracks or wear if they do not wipe properly.
--
blades
H
Doors and engine Check that all doors and the engine hood operate smoothly as well as the back
hood hatch. Also make sure that all latches lock securely. Lubricate if necessary.
MA-33, "Lubricating
Make sure that the secondary latch keeps the hood from opening when the pri-
Locks, Hinges and Hood
mary latch is released. I
Latches"
When driving in areas using road salt or other corrosive materials, check lubri-
cation frequently.
Lamps LT-27, "Aiming Adjust-
Make sure that the head lamps, stop lamps, tail lamps, turn signal lamps, and J
ment" for US, LT-43,
other lamps are all operating properly and installed securely. Also check head
"Aiming Adjustment" for
lamp aim. Clean the head lamps on a regular basis.
Canada
K
INSIDE THE VEHICLE
The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the
vehicle, etc.
Item Reference page MA
Warning lamps and Make sure that all warning lamps and buzzers/chimes are operating properly. DI-27, "Electrical Com-
buzzers/chimes ponents Inspection"
Windshield wiper and Check that the wipers and washer operate properly and that the wipers do not M
--
washer streak.
Windshield defroster Check that the air comes out of the defroster outlets properly and in sufficient
--
quantity when operating the heater or air conditioner.
Steering wheel Check that it has the specified play. Be sure to check for changes in the steering PS-8, "CHECKING
condition, such as excessive play, hard steering or strange noises. STEERING WHEEL
PLAY"
Seats Check seat position controls such as seat adjusters, seat back recliner, etc. to
make sure they operate smoothly and that all latches lock securely in every
position. Check that the head restraints move up and down smoothly and that --
the locks (if equipped) hold securely in all latched positions. Check that the
latches lock securely for folding-down rear seat backs.
Seat belts Check that all parts of the seat belt system (e.g. buckles, anchors, adjusters and SB-8, "Seat Belt Inspec-
retractors) operate properly and smoothly and are installed securely. Check the tion", MA-34, "Checking
belt webbing for cuts, fraying, wear or damage. Seat Belts, Buckles,
Retractors, Anchors and
Adjusters"
Accelerator pedal Check the pedal for smooth operation. Keep the floor mats away from the pedal. --
Revision: February 2006 MA-5 2005 Xterra
GENERAL MAINTENANCE
Item Reference page
Brakes Check that the brake does not pull the vehicle to one side when applied. --
Brake pedal and Check the pedal for smooth operation and make sure it has the proper distance BR-6, "Inspection and
booster under it when depressed fully. Check the brake booster function. Keep the floor Adjustment", BR-16,
mats away from the pedal. "On-Vehicle Service"
Parking brake Check that the parking brake control has the proper travel and make sure that
PB-3, "On-Vehicle Ser-
the vehicle is held securely on a fairly steep hill when only the parking brake is
vice"
applied.
Automatic transmis- On a fairly steep hill check that the vehicle is held securely with the selector
sion "Park" mecha- lever in the P position without applying the brakes. --
nism
UNDER THE HOOD AND VEHICLE
The maintenance items listed here should be checked periodically (e.g. each time you check the engine oil or refuel).
Item Reference page
Windshield washer Check that there is adequate fluid in the tank.
--
fluid
Engine coolant level Check the coolant level when the engine is cold. MA-13
Radiator and hoses Check the front of the radiator and clean off any dirt, insects, leaves, etc., that
may have accumulated. Make sure the hoses have no cracks, deformation, --
deterioration or loose connections.
Brake fluid level Make sure that the brake fluid level is between the "MAX" and "MIN" lines on the
MA-30
reservoirs
Battery Check the fluid level in each cell. It should be between the "MAX" and "MIN"
lines. Vehicles operated in high temperatures or under severe conditions require --
frequent checks of the battery fluid level.
Engine drive belt Make sure that no belt is frayed, worn, cracked or oily. MA-13
Engine oil level Check the level on the dipstick after parking the vehicle on a level spot and turn-
MA-17
ing off the engine.
Power steering fluid Check the level on the reservoir with the engine off. Check the lines for improper
MA-32
level and lines attachment, leaks, cracks, etc.
Automatic transmis- Check the level on the dipstick after putting the selector lever in "P" with the
MA-22
sion fluid level engine idling.
Exhaust system Make sure there are no loose supports, cracks or holes. If the sound of the
exhaust seems unusual or there is a smell of exhaust fumes, immediately locate MA-22
the trouble and correct it.
Underbody The underbody is frequently exposed to corrosive substances such as those
used on icy roads or to control dust. It is very important to remove these sub-
stances, otherwise rust will form on the floor pan, frame, fuel lines and around
--
the exhaust system. At the end of winter, the underbody should be thoroughly
flushed with plain water, being careful to clean those areas where mud and dirt
can easily accumulate.
Fluid leaks Check under the vehicle for fuel, oil, water or other fluid leaks after the vehicle
has been parked for a while. Water dripping from the air conditioner after use is
--
normal. If you should notice any leaks or gasoline fumes are evident, check for
the cause and correct it immediately.
Revision: February 2006 MA-6 2005 Xterra
PERIODIC MAINTENANCE
PERIODIC MAINTENANCE PFP:00026
A
Introduction of Periodic Maintenance ELS001HK
Two different maintenance schedules are provided, and should be used, depending upon the conditions in
which the vehicle is mainly operated. After 60,000 miles (96,000 km) or 48 months, continue the periodic B
maintenance at the same mileage or time intervals, whichever comes first.
Follow Periodic Maintenance Schedule 1 if your driving habits frequently includes Emission Control Sys- MA-7
one or more of the following driving conditions: tem Maintenance C
G Repeated short trips of less than 5 miles (8 km).
G Repeated short trips of less than 10 miles (16 km) with outside temperatures
remaining below freezing.
D
Schedule 1 G Operating in hot weather in stop-and-go "rush hour" traffic.
Chassis and Body
G Extensive idling and/or low speed driving for long distances, such as police, MA-7
Maintenance
taxi or door-to-door delivery use.
E
G Driving in dusty conditions.
G Driving on rough, muddy, or salt spread roads.
G Towing a trailer or using a car-top carrier.
F
Emission Control Sys- MA-9
Follow Periodic Maintenance Schedule 2 if none of the driving conditions shown tem Maintenance
Schedule 2
in Schedule 1 apply to the driving habits. Chassis and Body MA-9
Maintenance
G
Maintenance for off-road driving (4WD only)
After driving the vehicle off-road through sand, mud, or water; more frequent maintenance may be required for H
the following items:
Brake pads and rotors
Brake lines and hoses I
Rear final drive oil, transmission fluid, and transfer fluid
Steering linkage
Drive shafts
J
Engine air cleaner filter
In-cabin microfilters
Schedule 1 ELS001HL K
EMISSION CONTROL SYSTEM MAINTENANCE
Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. [ ]: At the mileage intervals only
MAINTENANCE OPERATION MAINTENANCE INTERVAL Reference MA
Perform at number of miles, Miles x 1,000 3.75 7.50 11.25 15 18.75 22.5 26.25 30 Section -
kilometers or months, which- (km x 1,000) (6) (12) (18) (24) (30) (36) (42) (48) Page or -
ever comes first. Months 3 6 9 12 15 18 21 24 Content Title
M
Drive belts NOTE (1) MA-13
Air cleaner filter NOTE (2) [R] MA-17
EVAP vapor lines I* MA-20
Fuel lines I* MA-16
Fuel filter NOTE (3) --
Engine coolant NOTE (4) MA-16
Engine oil R R R R R R R R MA-17
Engine oil filter R R R R R R R R MA-18
Spark plugs (PLATINUM-
Replace every 105,000 miles (169,000 km). MA-19
TIPPED type)
Intake and exhaust valve
NOTE (5) EM-138
clearance*
Revision: February 2006 MA-7 2005 Xterra
PERIODIC MAINTENANCE
MAINTENANCE OPERATION MAINTENANCE INTERVAL Reference
Perform at number of miles, Miles x 1,000 33.75 37.5 41.25 45 48.75 52.5 56.25 60 Section -
kilometers or months, which- (km x 1,000) (54) (60) (66) (72) (78) (84) (90) (96) Page or -
ever comes first. Months 27 30 33 36 39 42 45 48 Content Title
Drive belts NOTE (1) I* MA-13
Air cleaner filter NOTE (2) [R] MA-17
EVAP vapor lines I* MA-20
Fuel lines I* MA-16
Fuel filter NOTE (3) MA-16
Engine coolant NOTE (4) R* MA-13
Engine oil R R R R R R R R MA-17
Engine oil filter R R R R R R R R MA-18
Spark plugs (PLATINUM-
Replace every 105,000 miles (169,000 km). MA-19
TIPPED type)
Intake and exhaust valve
NOTE (5) EM-138
clearance*
(1) After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found
damaged, or if the auto tensioner reading reaches the maximum limit.
(2) If operating mainly in dusty conditions, more frequent maintenance may be required.
(3) Maintenance-free item. For service procedures, go to the FL section.
(4) After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months.
(5) If valve noise increases, inspect valve clearance.
* Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform
such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are
required.
CHASSIS AND BODY MAINTENANCE
Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. L = Lubricate. [ ]: At the mileage intervals only.
MAINTENANCE OPERATION MAINTENANCE INTERVAL Reference
Miles x Section
1,000 3.75 7.5 11.25 15 18.75 22.5 26.25 30 - Page
Perform at number of miles, kilometers or or
(km x (6) (12) (18) (24) (30) (36) (42) (48)
months, whichever comes first. - Content
1,000) 3 6 9 12 15 18 21 24
Months Title
Brake lines and cables I I MA-30
Brake pads and rotors I I I I MA-31
Automatic transmission fluid NOTE (1) I I MA-22
MA-25,
Transfer fluid and front final drive oil NOTE (1) I I
MA-26
Rear final drive oil NOTE (1) I I MA-27
Steering gear, linkage, axle, and suspension MA-31,
I I I I
parts MA-32
Tire rotation NOTE (2) MA-30
Drive shaft boots and propeller shaft (4WD) I I I I MA-26
Exhaust system I I I I MA-22
In-cabin microfilter R R MA-21
Revision: February 2006 MA-8 2005 Xterra
PERIODIC MAINTENANCE
MAINTENANCE OPERATION MAINTENANCE INTERVAL Reference
A
Miles x Section
1,000 33.75 37.5 41.25 45 48.75 52.5 56.25 60 - Page
Perform at number of miles, kilometers or or
(km x (54) (60) (66) (72) (78) (84) (90) (96)
months, whichever comes first. - Content
1,000) 27 30 33 36 39 42 45 48 B
Months Title
Brake lines and cables I I MA-30
Brake pads and rotors I I I I MA-31 C
Automatic transmission fluid NOTE (1) I I MA-22
MA-25,
Transfer fluid and front final drive oil NOTE (1) I I D
MA-26
Rear final drive oil NOTE (1) I I MA-27
Steering gear, linkage, axle, and suspension MA-31,
parts
I I I I
MA-32
E
Tire Rotation NOTE (2) MA-30
Drive shaft boots and propeller shaft (4WD) I I I I MA-26
F
Exhaust system I I I I MA-22
In-cabin microfilter R R MA-21
(1) If towing a trailer, or using a car-top carrier, or driving on rough or muddy roads, change (not just inspect) oil at every 30,000 miles G
(48,000 km) or 24 months.
(2) Refer to "Tire rotation" under the "General maintenance" heading earlier in this section.
H
Schedule 2 ELS001HM
EMISSION CONTROL SYSTEM MAINTENANCE
Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. [ ]: At the mileage intervals only
MAINTENANCE OPERATION MAINTENANCE INTERVAL I
Reference
Perform at number of miles, Miles x 1,000 7.5 15 22.5 30 37.5 45 52.5 60 Section - Page
kilometers or months, whichever (km x 1,000) (12) (24) (36) (48) (60) (72) (84) (96) or - Content
comes first. Months 6 12 18 24 30 36 42 48 Title J
Drive belts NOTE (1) I* MA-13
Air cleaner filter [R] [R] MA-17
K
EVAP vapor lines I* I* MA-20
Fuel lines I* I* MA-16
Fuel filter NOTE (2) MA-16 MA
Engine coolant NOTE (3) R* MA-13
Engine oil R R R R R R R R MA-17
M
Engine oil filter R R R R R R R R MA-18
Spark plugs (PLATINUM-
Replace every 105,000 miles (169,000 km). MA-19
TIPPED type)
Intake and exhaust valve clear-
NOTE (4) EM-138
ance*
(1) After 60,000 miles (96,000 km) or 48 months, inspect every 15,000 miles (24,000 km) or 12 months. Replace the drive belts if found
damaged, or if the auto tensioner reading reaches the maximum limit.
(2) Maintenance-free item. For service procedures, go to FL section.
(3) After 60,000 miles (96,000 km) or 48 months, replace every 30,000 miles (48,000 km) or 24 months.
(4) If valve noise increases, inspect valve clearance.
* Maintenance items and intervals with "*" are recommended by NISSAN for reliable vehicle operation. The owner need not perform
such maintenance in order to maintain the emission warranty or manufacturer recall liability. Other maintenance items and intervals are
required.
Revision: February 2006 MA-9 2005 Xterra
PERIODIC MAINTENANCE
CHASSIS AND BODY MAINTENANCE
Abbreviations: R = Replace. I = Inspect. Correct or replace if necessary. L = Lubricate. [ ]: At the mileage interval only.
MAINTENANCE OPERATION MAINTENANCE INTERVAL Reference
Section
Miles x 1,000 7.5 15 22.5 30 37.5 45 52.5 60 - Page
Perform at number of miles, kilome- or
(km x 1,000) (12) (24) (36) (48) (60) (72) (84) (96)
ters or months, whichever comes first. - Content
Months 6 12 18 24 30 36 42 48
Title
Brake lines and cables I I I I MA-30
Brake pads and rotors I I I I MA-31
Automatic transmission fluid I I I I MA-22
MA-25,
Transfer fluid and front final drive oil I I I I
MA-26
Rear final drive oil I I I I MA-27
Steering gear, linkage, axle, and sus- MA-31,
I I
pension parts. MA-32
Tire rotation NOTE (1) MA-30
Drive shaft boots and propeller shaft
I I I I MA-26
(4WD)
Exhaust system I I MA-22
In-cabin microfilter R R R R MA-21
(1) Refer to "Tire rotation" under the "General maintenance" heading earlier in this section.
Revision: February 2006 MA-10 2005 Xterra
RECOMMENDED FLUIDS AND LUBRICANTS
RECOMMENDED FLUIDS AND LUBRICANTS PFP:00000
A
Fluids and Lubricants ELS001HN
Capacity (Approximate)
Description Recommended Fluids/Lubricants
Metric US measure Imp measure B
Unleaded gasoline with an octane rat-
Fuel 80 21 1/8 gal 17 5/8 gal
ing of at least 87 AKI (RON 91) *9
C
With oil filter
5.1 5 3/8 qt 4 1/2 qt
Engine oil change G API Certification Mark*1
Drain and refill Without oil G API grade SL, Energy Conserving*1
4.8 5 1/8 qt 4 1/4 qt D
filter change G ILSAC grade GF-III*1
Dry engine (engine overhaul) 6.3 6 5/8 qt 5 1/2 qt
With reservoir Genuine NISSAN Long Life Anti-freeze
Cooling system 10.2 2 3/4 gal 2 1/4 gal E
at MAX level coolant or equivalent
Automatic transmission fluid (ATF) 10.3 10 7/8 qt 9 1/8 qt Genuine NISSAN Matic J ATF *2
2WD 3.98 4 1/4 qt 3 1/2 qt Genuine NISSAN Manual Transmis- F
Manual transmis-
sion Fluid (MTF) HQ Multi 75W-85 or
sion fluid (MTF)
4WD 4 3/8 qt 3 5/8 qt API GL-4, Viscosity SAE 75W-85 or
(6 M/T model) 4.18
75W-90
G
API GL-5 Synthetic 75W-90 Gear Oil
C200 1.6 3 3/8 pt 2 7/8 pt (Part No. 999MP-DF200P) or equiva-
lent *6
Rear final drive oil
API GL-5 Synthetic 75W-140 Gear Oil H
M226 2.01 4 1/4 pt 3 1/2 pt (Part No. 999MP-DF100P) or equiva-
lent *6
Genuine NISSAN Matic D ATF (Conti- I
Transfer fluid TX15B 2.0 2 1/8 qt 1 3/4 qt nental U.S and Alaska) or Canada NIS-
SAN Automatic Transmission Fluid *8
Front final drive oil 0.85 1 3/4 pt 1 1/2 pt API GL-5 Viscosity SAE 80W-90 *7 J
Power steering fluid (PSF) 1.0 2 1/8 pt 1 3/4 pt Genuine NISSAN PSF or equivalent *3
Genuine NISSAN Super Heavy Duty
Brake fluid -- -- -- Brake Fluid or equivalent, DOT 3 (US K
FMVSS No. 116) *4
Brake grease -- -- -- PBC (poly butyl cuprysil)
Brake pad plate grease -- -- -- Molykote AS880N grease MA
Multi-purpose grease -- -- -- NLGI No. 2 (lithium soap base)
Genuine NISSAN Windshield Washer
M
Windshield washer fluid 4.5 1 1/4 gal 1 gal Concentrate Cleaner & Anti-freeze or
equivalent
A/C system refrigerant 0.70 ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
