Image preview - the first page of the document
LT


>> Download LT documenatation <<

Text preview - extract from the document
K ELECTRICAL

                                                                                                                                                                     A


                                                                                                                                                                     B
                                                                                                          SECTION
                                                                                                    LIGHTING SYSTEM                                                  C


                                                                                                                                                                     D


                                                                                                                                                                     E
                                                                  CONTENTS
PRECAUTIONS ......................................................... 3 .           System Description ................................................ 21 .         F
 Precautions for Supplemental Restraint System                                        FRONT FOG LAMP OPERATION ...................... 21                   .
 (SRS) "AIR BAG" and "SEAT BELT PRE-TEN-                                            Wiring Diagram -- F/FOG -- ................................. 22        .
 SIONER" ................................................................. 3
                                                                        .           Aiming Adjustment ................................................. 23 .        G
 Wiring Diagrams and Trouble Diagnosis ................. 3              .           Removal and Installation ....................................... 24    .
COMBINATION SWITCH ........................................... 4        .           Bulb Replacement ................................................. 24  .
 Check ...................................................................... 4
                                                                        .         TURN SIGNAL AND HAZARD WARNING LAMPS... 25
                                                                                                                                                                     H
 Replacement ........................................................... 5
                                                                        .           System Description ................................................ 25 .
HEADLAMP (FOR USA) ........................................... 6        .             TURN SIGNAL OPERATION ............................. 25               .
 System Description ................................................. 6 .             HAZARD LAMP OPERATION ............................ 25                .
   LOW BEAM OPERATION .................................... 6            .             REMOTE KEYLESS ENTRY SYSTEM OPERA-                                             I
   HIGH BEAM OPERATION/FLASH-TO-PASS                                                  TION ................................................................... 26
                                                                                                                                                           .
   OPERATION ........................................................ 6 .           Wiring Diagram -- TURN -- .................................. 27        .
   VEHICLE SECURITY SYSTEM ........................... 6                .           Trouble Diagnoses ................................................ 29  .         J
 Wiring Diagram -- H/LAMP -- ................................ 7         .           Electrical Components Inspection ......................... 29          .
 Trouble Diagnoses .................................................. 8 .             COMBINATION FLASHER UNIT CHECK .......... 29                         .
 Bulb Replacement ................................................... 9 .         TRAILER TOW ......................................................... 30 .        LT
 Aiming Adjustment .................................................. 9 .           System Description ................................................ 30 .
   LOW BEAM .......................................................... 9.             TRAILER TAIL LAMP OPERATION ................... 30                   .
HEADLAMP (FOR CANADA) -- DAYTIME LIGHT                                                TRAILER STOP, TURN SIGNAL AND HAZARD
SYSTEM -- ...............................................................11
                                                                        .             LAMP OPERATION ............................................ 30       .         L
 System Description (For Canada) ..........................11           .           Wiring Diagram -- T/TOW -- ................................ 31         .
   HEADLAMP OPERATION ..................................11              .           Trouble Diagnoses ................................................ 32  .
   DAYTIME LIGHT OPERATION .......................... 12                .             TRAILER TOW CONTROL UNIT INSPECTION                                           M
   OPERATION (FOR CANADA) ........................... 12                .             TABLE ................................................................ 32
                                                                                                                                                           .
 Circuit Diagram ..................................................... 13
                                                                        .         ILLUMINATION ........................................................ 33 .
 Wiring Diagram -- DTRL -- .................................. 14        .           System Description ................................................ 33 .
 Trouble Diagnoses ................................................ 17  .           Wiring Diagram -- ILL -- ....................................... 34    .
   DAYTIME LIGHT CONTROL UNIT INSPECTION                                          INTERIOR ROOM LAMP ......................................... 36          .
   TABLE ................................................................ 17
                                                                        .           Component Parts and Harness Connector Location 36                      ...
 Bulb Replacement ................................................. 17  .           System Description ................................................ 37 .
 Aiming Adjustment ................................................ 17  .             MODELS WITHOUT POWER DOOR LOCKS ... 37
PARKING, LICENSE AND TAIL LAMPS ................. 18                    .             MODELS WITH POWER DOOR LOCKS ........... 37                          .
 Wiring Diagram -- TAIL/L -- ................................. 18       .           Wiring Diagram -- ROOM/L -- ............................. 39           .
STOP LAMP ............................................................ 19
                                                                        .             MODELS WITHOUT POWER DOOR LOCKS ... 39
 Wiring Diagram -- STOP/L -- ............................... 19         .             MODELS WITH POWER DOOR LOCKS ........... 40                          .
BACK-UP LAMP ..................................................... 20   .           Trouble Diagnosis .................................................. 42.
 Wiring Diagram -- BACK/L -- .............................. 20          .             MODELS WITHOUT POWER DOOR LOCKS ... 42
FRONT FOG LAMP ................................................. 21     .             MODELS WITH POWER DOOR LOCKS ........... 43                          .



                                                                             LT-1
BULB SPECIFICATIONS ......................................... 45  .
 Bulb Specifications ................................................ 45
                                                                  .
  HEADLAMP ........................................................ 45
                                                                  .
  EXTERIOR LAMP .............................................. 45 .
  INTERIOR LAMP ................................................ 45
                                                                  .




                                                                      LT-2
                                              PRECAUTIONS

PRECAUTIONS                                                         PFP:00001
                                                                                                                          A
Precautions for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT
BELT PRE-TENSIONER"                                                                                          EKS003MW


The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along                             B
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front               C
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:                                                                                                                  D
q    To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
     in the event of a collision which would result in air bag inflation, all maintenance must be per-
     formed by an authorized NISSAN/INFINITI dealer.                                                                      E
q    Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
     sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
     Bag Module, see the SRS section.                                                                                     F
q    Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
     Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
     harness connectors.
                                                                                                                         G
Wiring Diagrams and Trouble Diagnosis                                                                         EKS0030Z


When you read wiring diagrams, refer to the following:
                                                                                                                          H
q  GI-13, "How to Read Wiring Diagrams".
q  PG-8, "POWER SUPPLY ROUTING" for power distribution circuit.
When you perform trouble diagnosis, refer to the following:                                                               I
q  GI-9, "HOW TO FOLLOW TEST GROUPS IN TROUBLE DIAGNOSES".
q  GI-25, "How to Perform Efficient Diagnosis for an Electrical Incident".
Check for any Service bulletins before servicing the vehicle.                                                             J


                                                                                                                         LT


                                                                                                                          L



                                                                                                                         M




                                                      LT-3
                     COMBINATION SWITCH

COMBINATION SWITCH                         PFP:25567

Check                                            EKS00317




                                          WKIA1713E




                            LT-4
                                      COMBINATION SWITCH

Replacement                                                                 EKS00318

                                                                                        A
For removal and installation of spiral cable, refer to SRS-43,
"DRIVER AIR BAG MODULE AND SPIRAL CABLE" .
q   Each switch can be replaced without removing combination
    switch base.                                                                        B



                                                                                        C


                                                                                        D
                                                                         SEL865L




q   To remove combination switch base, remove base attaching                            E
    screws.


                                                                                        F


                                                                                       G


                                                                         MEL205B
                                                                                        H

q   Before installing the steering wheel, align the turn signal cancel
    tab with the notch of the combination switch. Refer to SRS-43,                      I
    "DRIVER AIR BAG MODULE AND SPIRAL CABLE" .


                                                                                        J


                                                                                       LT


                                                                                        L



                                                                                       M




                                                                         ARS152




                                                    LT-5
                                       HEADLAMP (FOR USA)

HEADLAMP (FOR USA)                                                                                   PFP:26010

System Description                                                                                        EKS0031A


The headlamps are controlled by the lighting switch which is built into the combination switch.
Power is supplied at all times
q   through 15A fuse (No. 37, located in the fuse and fusible link box)
q   to lighting switch terminal 8 and
q   through 15A fuse (No. 38, located in the fuse and fusible link box)
q   to lighting switch terminal 5.
LOW BEAM OPERATION
With the lighting switch in the headlamp ON (2ND) position and low beam (B) position, power is supplied
q   from lighting switch terminal 7
q   to headlamp LH terminal D and
q   from lighting switch terminal 10
q   to headlamp RH terminal D.
Ground is supplied to headlamp LH/RH terminal E through body grounds E12 and E54.
With power and ground supplied, the low beams illuminate.
HIGH BEAM OPERATION/FLASH-TO-PASS OPERATION
With the lighting switch in the flash-to-pass (C) position or the headlamp ON (2ND) position and high beam (A)
position, power is supplied
q   from lighting switch terminal 6
q   to headlamp LH terminal M and
q   from lighting switch terminal 9
q   to headlamp RH terminal M and
q   to combination meter terminal 11 for the high beam indicator.
Ground is supplied to terminal 10 of the combination meter through body grounds M14 and M68.
Ground is supplied to headlamp LH/RH terminal E through body grounds E12 and E54.
With power and ground supplied, the high beams and the high beam indicator illuminate.
VEHICLE SECURITY SYSTEM
The vehicle security system will flash the high beams if the system is triggered. Refer to BL-49, "System
Description" .




                                                    LT-6
                         HEADLAMP (FOR USA)

Wiring Diagram -- H/LAMP --                         EKS0031B

                                                                A


                                                                B



                                                                C


                                                                D


                                                                E



                                                                F


                                                               G


                                                                H



                                                                I


                                                                J


                                                               LT


                                                                L



                                                               M




                                              WKWA0355E




                                LT-7
                                               HEADLAMP (FOR USA)

Trouble Diagnoses                                                                                                                EKS0031C


            Symptom                            Possible cause                                     Repair order
Neither headlamp LH nor headlamp     1. Lighting switch                   1. Check lighting switch.
RH operate.
Headlamp LH does not operate, but    1. Bulb                              1. Check bulb.
headlamp RH operates properly.       2. Headlamp LH ground circuit        2. Check continuity between headlamp LH terminal E and
                                     3. 15A fuse                             grounds E12 and E54.
                                     4. Lighting switch                   3. Check 15A fuse (No. 38, located in fuse and fusible link
                                                                             box). Verify battery positive voltage is present at termi-
                                                                             nal 5 of lighting switch.
                                                                          4. Check lighting switch.
Headlamp RH does not operate,        1. Bulb                              1. Check bulb.
but headlamp LH operates properly.   2. Headlamp RH ground circuit        2. Check continuity between headlamp RH terminal E and
                                     3. 15A fuse                             grounds E12 and E54.
                                     4. Lighting switch                   3. Check 15A fuse (No. 37, located in fuse and fusible link
                                                                             box). Verify battery positive voltage is present at termi-
                                                                             nal 8 of lighting switch.
                                                                          4. Check lighting switch.
High beam LH does not operate,       1. Bulb                              1. Check bulb.
but low beam LH operates.            2. Open in high beam LH circuit      2. Check R/G wire between lighting switch terminal 6 and
                                     3. Lighting switch                      headlamp LH terminal M for an open circuit.
                                                                          3. Check lighting switch.
Low beam LH does not operate, but    1. Bulb                              1. Check bulb.
high beam LH operates.               2. Open in low beam LH circuit       2. Check R wire between lighting switch terminal 7 and
                                     3. Lighting switch                      headlamp LH terminal D for an open circuit.
                                                                          3. Check lighting switch.
High beam RH does not operate,       1. Bulb                              1. Check bulb.
but low beam RH operates.            2. Open in high beam RH circuit      2. Check R/W wire between lighting switch terminal 9 and
                                     3. Lighting switch                      headlamp RH terminal M for an open circuit.
                                                                          3. Check lighting switch.
Low beam RH does not operate,        1. Bulb                              1. Check bulb.
but high beam RH operates.           2. Open in low beam RH circuit       2. Check R/B wire between lighting switch terminal 10
                                     3. Lighting switch                      and headlamp RH terminal D for an open circuit.
                                                                          3. Check lighting switch.
High beam indicator does not work.   1. Bulb                              1. Check bulb in combination meter.
                                     2. High beam indicator ground cir-   2. Check continuity between combination meter terminal
                                        cuit                                 10 and grounds M14 and M68.
                                     3. Open in high beam circuit         3. Check R/G wire between lighting switch terminal 6 and
                                                                             combination meter terminal 11 for an open circuit.




                                                             LT-8
                                      HEADLAMP (FOR USA)

Bulb Replacement                                                                                 EKS0031D

                                                                                                              A
The headlamp is a semi-sealed beam type which uses a replaceable
halogen bulb. The bulb can be replaced from the engine compart-
ment side without removing the headlamp body.
q    Grasp only the plastic base when handling the bulb. Never                                                B
     touch the glass envelope.
1. Disconnect the battery cable.
                                                                                                              C
2. Disconnect the harness connector from the back side of the
     bulb.
3. Remove bulb retaining ring.
                                                                                                              D
4. Remove the headlamp bulb carefully. Do not shake or rotate the
     bulb when removing it.
5. Install in the reverse order of removal.
                                                                                                              E
CAUTION:
Do not leave headlamp reflector without bulb for a long period
of time. Dust, moisture, smoke, etc. entering headlamp body
may affect the performance of the headlamp. Remove headlamp                                                   F
bulb from the headlamp reflector just before a replacement bulb
is installed.
                                                                                                             G

                                                                                               WEL790A

                                                                                                              H
Aiming Adjustment                                                                                 EKS0031E


When performing headlamp aiming adjustment, use an aiming wall screen.
For details, refer to local regulations.                                                                      I
Before performing aiming adjustment, check the following.
1. Keep all tires inflated to correct pressures.
2. Place vehicle on flat surface.                                                                             J
3. See that the vehicle is unloaded (except for full levels of coolant, engine oil and fuel, and spare
    tire, jack, and tools). Have the driver or equivalent weight placed in the driver's seat.
LOW BEAM                                                                                                     LT
NOTE:
The horizontal headlamp aim cannot be adjusted. Only vertical aim is adjustable.
1. Turn headlamp low beam on.                                                                                 L
2. Use adjusting screw to adjust the vertical aim of the lamp.
    q Cover the opposite lamp and ensure fog lamps, if
      equipped, are turned off.                                                                              M




                                                                                               WEL918A




                                                   LT-9
                                      HEADLAMP (FOR USA)

    q   Adjust beam pattern until cut-off line (top edge of illumination area) is positioned at same height
        off ground as bulb center (on H-line). Measure cut-off line within distance A on H-line. See aim-
        ing chart following.




                                                                                                 WEL536A

If the vehicle front body has been repaired and/or the headlamp assembly has been replaced, check aiming.
Use the aiming chart shown in the figure.
q    Basic illuminating area (shaded) for adjustment should be within the range shown on the aiming
     chart. Adjust headlamps accordingly.




                                                  LT-10
              HEADLAMP (FOR CANADA) -- DAYTIME LIGHT SYSTEM --

HEADLAMP (FOR CANADA) -- DAYTIME LIGHT SYSTEM --                                                          PFP:26010
                                                                                                                          A
System Description (For Canada)                                                                               EKS0031F


The headlamp system for Canada vehicles contains a daytime light control unit that activates the high beam
headlamps at approximately half illumination whenever the engine is running. If the parking brake is applied              B
before the engine is started the daytime lights will not be illuminated. The daytime lights will illuminate once the
parking brake is released. Thereafter, the daytime lights will continue to operate when the parking brake is
applied. If the daytime light control unit receives a ground signal from the generator, the daytime lights will not
be illuminated. The daytime lights will illuminate once a battery positive voltage signal is sent to the daytime          C
light control unit from the generator.
Power is supplied at all times
q    through 15A fuse (No. 38, located in the fuse and fusible link box)                                                  D
q    to daytime light control unit terminal 3 and
q    to lighting switch terminal 5.
                                                                                                                          E
Power is also supplied at all times
q    through 15A fuse (No. 37, located in the fuse and fusible link box)
q    to daytime light control unit terminal 2 and
                                                                                                                          F
q    to lighting switch terminal 8.
With the ignition switch in the ON or START position, power is supplied
q    through 10A fuse [No. 5, located in the fuse block (J/B)]                                                           G
q    to daytime light control unit terminal 12.
With the ignition switch in the START position, power is supplied
q    through 7.5A fuse [No. 7, located in the fuse block (J/B)]                                                           H
q    to daytime light control unit terminal 1.
Ground is supplied to daytime light control unit terminal 9 through body grounds E12 and E54.
                                                                                                                          I
HEADLAMP OPERATION
Low Beam Operation
When the lighting switch is turned to the headlamp ON (2ND) position, low beam (B), power is supplied                     J
q   from lighting switch terminal 10
q   to headlamp RH terminal D and
q   to daytime light control unit terminal 4.                                                                            LT
Ground is supplied to headlamp RH terminal E through body grounds E12 and E54.
Also, when the lighting switch is turned to the headlamp ON (2ND) position, low beam (B), power is supplied
q   from lighting switch terminal 7                                                                                       L
q   to headlamp LH terminal D.
Ground is supplied
                                                                                                                         M
q   to headlamp LH terminal E
q   from daytime light control unit terminal 7
q   through daytime light control unit terminal 9
q   through body grounds E12 and E54.
With power and ground supplied, the low beam headlamps illuminate.
High Beam Operation/Flash-to-pass Operation
When the lighting switch is turned to the headlamp ON (2ND) position, high beam (A) or flash-to-pass (C)
position, power is supplied
q   from lighting switch terminal 9
q   to headlamp RH terminal M and
q   to daytime light control unit terminal 8.
Also, when the lighting switch is turned to the headlamp ON (2ND) position, high beam (A) or flash-to-pass (C)
position, power is supplied
q   from lighting switch terminal 6
q   to combination meter terminal 11 for the high beam indicator and
                                                     LT-11
                      HEADLAMP (FOR CANADA) -- DAYTIME LIGHT SYSTEM --

q   to daytime light control unit terminal 5
q   through daytime light control unit terminal 6
q   to headlamp LH terminal M.
Ground is supplied in the same manner as low beam operation.
Ground is supplied to combination meter terminal 10 through body grounds M14 and M68.
With power and ground supplied, the high beam headlamps and high beam indicator illuminate.
DAYTIME LIGHT OPERATION
With the engine running, the lighting switch in the OFF or 1ST position and parking brake released, power is
supplied
q   through daytime light control unit terminal 6
q   to headlamp LH terminal M
q   through headlamp LH terminal E
q   to daytime light control unit terminal 7
q   through daytime light control unit terminal 8
q   to headlamp RH terminal M.
Ground is supplied to headlamp RH terminal E through body grounds E12 and E54.
Because the high beam headlamps are now wired in series, they operate at half illumination.
OPERATION (FOR CANADA)
After starting the engine with the lighting switch in the OFF or parking lamp (1ST) position, the headlamp high
beams automatically turn on. Lighting switch operations other than the above are the same as conventional
light systems.
                 Engine                              With engine stopped                                 With engine running
                                             OFF              1ST             2ND             OFF                1ST               2ND
    Lighting switch
                                         A    B     C    A     B    C     A    B     C    A     B    C      A    B     C       A   B     C

                        High beam        X    X     O    X     X    O     O    X     O               O       *     *   O       O   X     O
    Headlamp
                        Low beam         X    X     X    X     X    X     X    O     X    X     X    X      X    X     X       X   O     X
    Clearance and tail lamp              X    X     X    O     O    O     O    O     O    X     X    X      O    O     O       O   O     O
    License and instrument illumina-
                                         X    X     X    O     O    O     O    O     O    X     X    X      O    O     O       O   O     O
    tion lamp

q    A: High beam position
q    B: Low beam position
q    C: Flash-to-pass position
q     O : Lamp ON
q     X : Lamp OFF

q       : Lamp dims. (Added functions)
q    *: When starting the engine with the parking brake released, the daytime lights will come ON.
     When starting the engine with the parking brake applied, the daytime lights won't come ON.




                                                                   LT-12
         HEADLAMP (FOR CANADA) -- DAYTIME LIGHT SYSTEM --

Circuit Diagram                                                       EKS0031G

                                                                                  A


                                                                                  B



                                                                                  C


                                                                                  D


                                                                                  E



                                                                                  F


                                                                                 G


                                                                                  H



                                                                                  I


                                                                                  J
                                                            LEL714A




                                                                                 LT


                                                                                  L



                                                                                 M




                              LT-13
         HEADLAMP (FOR CANADA) -- DAYTIME LIGHT SYSTEM --

Wiring Diagram -- DTRL --                                         EKS0031H




                                                            WKWA1098E




                              LT-14
HEADLAMP (FOR CANADA) -- DAYTIME LIGHT SYSTEM --


                                                                A


                                                                B



                                                                C


                                                                D


                                                                E



                                                                F


                                                               G


                                                                H



                                                                I


                                                                J


                                                               LT


                                                                L



                                                               M




                                                   WKWA1099E




                     LT-15
HEADLAMP (FOR CANADA) -- DAYTIME LIGHT SYSTEM --




                                                   WKWA0358E




                     LT-16
             HEADLAMP (FOR CANADA) -- DAYTIME LIGHT SYSTEM --

Trouble Diagnoses                                                                                                          EKS0031I

DAYTIME LIGHT CONTROL UNIT INSPECTION TABLE                                                                                            A
  Terminal    Wire
                                  Item                                       Condition                        Voltage (Approx.)
    No.       color
     1        L/OR    Ignition switch start signal   Ignition switch in START position                               12                B
                                                     All other conditions                                            0
     2         Y/G    Power source for head-
                                                                                --                                   12                C
                      lamp RH
     3         Y/B    Power source for head-
                                                                                --                                   12
                      lamp LH
                                                                                                                                       D
     4         R/B    Lighting switch headlamp       Lighting switch in the headlamp ON (2ND) position and
                                                                                                                     12
                      RH low beam output             low beam (B) position
                                                     All other conditions                                            0
                                                                                                                                       E
     5         R/G    Lighting switch headlamp       Lighting switch in the flash-to-pass (C) position or
                      LH high beam output            headlamp ON (2ND) position and high beam (A) posi-              12
                                                     tion
                                                                                                                                       F
                                                     All other conditions                                            0
     6         R/Y    Headlamp LH high beam          Lighting switch in the flash-to-pass (C) position or
                                                     headlamp ON (2ND) position and high beam (A) posi-              12
                                                     tion                                                                             G
                                                     With parking brake released, engine running and light-
                                                     ing switch in OFF or parking and tail lamp ON (1ST)
                                                     positions                                                                         H
                                                                                                                     12
                                                     CAUTION:
                                                     Block wheels and ensure selector lever is in P or N
                                                     position.
                                                                                                                                       I
                                                     All other conditions                                            0
     7        B/W     Headlamp LH control            Lighting switch in the flash-to-pass (C) position or
                                                                                                                     0
                      (ground)                       headlamp ON (2ND) position                                                        J
                                                     All other conditions                                            6
     8        R/W     Lighting switch headlamp       Lighting switch in the flash-to-pass (C) position or
                      RH high beam output            headlamp ON (2ND) position and high beam (A) posi-              12               LT
                                                     tion
                                                     With parking brake released, engine running and light-
                                                     ing switch in OFF or parking and tail lamp ON (1ST)
                                                                                                                                       L
                                                     positions
                                                                                                                     6
                                                     CAUTION:
                                                     Block wheels and ensure selector lever is in P or N
                                                     position.                                                                        M
                                                     All other conditions                                            0
     9          B     Ground                                                    --                                   --
     10         Y     Parking brake switch           Parking brake released                                          12
                                                     Parking brake applied                                           0
     11        Y/B    Generator                      When engine is running                                          12
                      (L terminal)
                                                     All other conditions                                            0
     12       G/W     Ignition switch ON signal      Ignition switch OFF, ACC positions                              0
                                                     Ignition switch ON, START positions                             12

Bulb Replacement                                                                                                           EKS0031J


Refer to LT-9, "Bulb Replacement" .
Aiming Adjustment                                                                                                         EKS0031K


Refer to LT-9, "Aiming Adjustment" .

                                                          LT-17
                PARKING, LICENSE AND TAIL LAMPS

PARKING, LICENSE AND TAIL LAMPS                    PFP:26550

Wiring Diagram -- TAIL/L --                             EKS0031L




                                                  WKWA1100E




                              LT-18
                              STOP LAMP

STOP LAMP                                  PFP:26550
                                                            A
Wiring Diagram -- STOP/L --                     EKS0031M




                                                            B



                                                            C


                                                            D


                                                            E



                                                            F


                                                           G


                                                            H



                                                            I


                                                            J


                                                           LT


                                                            L



                                                           M




                                          WKWA1135E




                                LT-19
                              BACK-UP LAMP

BACK-UP LAMP                                  PFP:26550

Wiring Diagram -- BACK/L --                        EKS0031N




                                             WKWA0361E




                                 LT-20
                                         FRONT FOG LAMP

FRONT FOG LAMP                                                                                       PFP:26150
                                                                                                                    A
System Description                                                                                      EKS0031O


Power is supplied at all times
q   through 15A fuse (No. 40, located in the fuse and fusible link box)                                             B
q   to front fog lamp relay terminal 5 and
q   through 15A fuse (No. 37, located in the fuse and fusible link box)
q   to lighting switch terminal 5.                                                                                  C
With the lighting switch in the headlamp ON (2ND) position and low beam (B) position, power is supplied
q   through lighting switch terminal 7
                                                                                                                    D
q   to front fog lamp switch terminal 31.
FRONT FOG LAMP OPERATION
The front fog lamp switch is built into the combination switch. The lighting switch must be in the headlamp ON      E
(2ND) position and low beam (B) position for front fog lamp operation.
With the front fog lamp switch in the ON position:
q   power is supplied to front fog lamp relay terminal 2                                                            F
q   through front fog lamp switch terminal 32
q   through front fog lamp switch terminal 31.
The front fog lamp relay is energized and power is supplied                                                        G
q   through front fog lamp relay terminal 3
q   to front fog lamp LH/RH terminal 1.
                                                                                                                    H
Ground is supplied to front fog lamp LH/RH terminal 2 and front fog lamp relay terminal 1 through body
grounds E12 and E54.
With power and ground supplied, the front fog lamps illuminate.
                                                                                                                    I


                                                                                                                    J


                                                                                                                   LT


                                                                                                                    L



                                                                                                                   M




                                                  LT-21
                             FRONT FOG LAMP

Wiring Diagram -- F/FOG --                          EKS0031P




                                              WKWA0839E




                                 LT-22
                                          FRONT FOG LAMP

Aiming Adjustment                                                           EKS0031Q

                                                                                        A
Before performing aiming adjustment, make sure of the following.
1. Keep all tires inflated to correct pressure.
2. Place vehicle on level ground.                                                       B
3. See that vehicle is unloaded (except for full levels of coolant,
    engine oil and fuel, and spare tire, jack, and tools). Have the
    driver or equivalent weight placed in driver's seat.
                                                                                        C


                                                                                        D
                                                                         WKIA1689E




1.   Set the distance between the screen and the center of the front                    E
     fog lamp lens.
2.   Turn front fog lamps ON.
                                                                                        F


                                                                                       G


                                                                         MEL327G
                                                                                        H

3.   Using adjusting screw, adjust front fog lamps so that the top
     edge of the high intensity zone is 100 mm (4 in) below the height                  I
     of the fog lamp centers.
     q When performing adjustment, if necessary, cover the
        headlamps and opposite fog lamp.
                                                                                        J


                                                                                       LT


                                                                                        L



                                                                                       M




                                                                         MEL328G




                                                    LT-23
                                          FRONT FOG LAMP

Removal and Installation                                                    EKS0031R


1.   Disconnect front fog lamp harness connector.
2.   Remove mounting bolt and remove lens and housing assembly
     from front bumper cover.
3.   Install in reverse order of removal. Ensure top of lens faces up.
4.   Tighten mounting bolt.
             : 5



◦ Jabse Service Manual Search 2020 ◦ Jabse Pravopis ◦ Other service manual resources online : FixyaeServiceinfo
