Image preview - the first page of the document
>> Download ACC documenatation <<Text preview - extract from the document
ACCELERATOR CONTROL SYSTEM C
ACCELERATOR CONTROL SYSTEM ..................... 2
. Removal and Installation ......................................... 2
Adjusting Accelerator Wire ...................................... 2
ACCELERATOR CONTROL SYSTEM
ACCELERATOR CONTROL SYSTEM PFP:18005
Removal and Installation EBS00EZD
Accelerator Pedal and Wire
q The accelerator wire should be adjusted when removing or replacing any parts of the Accelerator
q Check that throttle valve opens fully when accelerator pedal is fully depressed. Also check that
the throttle valve returns to the idle position when the pedal is released.
q Check the accelerator control parts for interference contact with any adjacent parts.
q When connecting the accelerator wire, be careful not to twist or scratch the inner wire.
q Refer toACS-23, "ASCD Wire Adjustment" .
Adjusting Accelerator Wire EBS00EZE
Adjust the accelerator wire with the engine warmed up to normal operating temperature and the ignition switch
turned to OFF.
1. Remove the vacuum hose connected to the throttle opener.
2. Connect a suitable vacuum hose to the vacuum pump.
3. Apply vacuum [more than -40.00 kPa (-300 mmHg, -11.81 inHg)]
until the throttle drum becomes free from the rod of the throttle
q Make sure that there is clearance between the throttle drum
