Image preview - the first page of the document
MSA5T0126A27928


>> Download MSA5T0126A27928 documenatation <<

Text preview - extract from the document
5-5    [W8A0]                      SERVICE PROCEDURE
8. Roll Connector


8. Roll Connector                                       7) Disconnect airbag connector on back of airbag
                                                        module.  Remove airbag
A: REMOVAL                                              module, and place it with pad side facing upward.
1) Turn ignition switch off.
2) Disconnect ground cable from battery and wait
for at least 20 seconds before starting work.
3) Remove lower cover.
4) Disconnect airbag connector (AB3) and (AB8)
below steering column.
CAUTION:
Do not reconnect airbag connector at steering
column until combination switch is securely re-
installed.
                                                                                               H5M0664

                                                        8) Using steering puller (A), remove steering
                                                        wheel.
                                                        CAUTION:
                                                        Do not allow connector to interfere when
                                                        removing steering wheel.



                                      G5M0312

5) Disconnect combination switch connectors
from body harness connector.
6) Set front wheels in straight ahead position.
Using T30 TORX bit, remove the two TORX
bolts.
                                                                                              S5M0436A

                                                        9) Remove steering column covers.
                                                        10) Removing the three retaining screws, remove
                                                        combination switch.




                                      H5M0662




                                                                                               S5M0220




                                                   14
                                     SERVICE PROCEDURE                                            [W8C0] 5-5
                                                                                               8. Roll Connector


11) Disconnect connectors and then detach com-             C: INSTALLATION
bination switch assembly.
12) Remove lighting switch and wiper switch from           CAUTION:
roll connector.                                            Failure to do this might damage roll connector.
                                                           1) Install lighting switch and wiper switch to roll
                                                           connector.
                                                           2) Before installing combination switch, check to
                                                           ensure that combination switch is off and front
                                                           wheels are set in the straight ahead position.
                                                           3) Install combination switch assembly and then
                                                           connect connectors.
                                                           4) Install column cover and centering roll connec-
                                                           tor.
                                                           5) Install steering wheel in neutral position. Care-
                                        B5M0940
                                                           fully insert roll connector pin (A) into hole on steer-
                                                           ing wheel.
                                                           NOTE:
B: ADJUSTMENT                                              If steering wheel angle requires fine adjustment,
1. CENTERING ROLL CONNECTOR                                adjust tie-rod.
Before installing steering wheel, make sure to cen-
ter roll connector built into combination switch.
1) Make sure that front wheels are positioned
straight ahead.
2) Install steering gearbox, steering shaft and
combination switch properly. Turn roll connector
pin (A) clockwise until it stops.
3) Then, back off roll connector pin (A) approxi-
mately 2.5 turns until " " marks aligned.

                                                                                                     H5M0663B

                                                           6) Install airbag module and lower cover in the
                                                           reverse order of removal.




                                       H5M0663B




                                                      15
