Image preview - the first page of the document
MSA5T0122A27565


>> Download MSA5T0122A27565 documenatation <<

Text preview - extract from the document
2-2   [W8A0]                          SERVICE PROCEDURE
8. Valve Clearance


8. Valve Clearance                                   5) Remove rocker cover.
                                                     6) When inspecting #1 and #3 cylinders:
A: INSPECTION                                           (1) Remove air intake duct as a unit.
CAUTION:
Inspection and adjustment of valve clearance
should be performed while engine is cold.
1) Set the vehicle onto the lift.
2) Disconnect battery ground cable.




                                                                                           B2M2012

                                                       (2) Remove resonator chamber.




                                       G6M0095

3) Remove engine coolant reservoir tank.




                                                                                           B2M2013

                                                       (3) Disconnect spark plug cords from spark
                                                       plugs (#1 and #3 cylinders).




                                       S2M0931

4) Remove timing belt cover (LH).




                                                                                           B2M2014

                                                       (4) Disconnect blow-by hose from rocker cover
                                                       (RH).



                                       B2M2031




                                                                                           B2M2015

                                                       (5) Lift-up the vehicle.
                                                       (6) Remove under cover.

                                                 8
                                    SERVICE PROCEDURE                                    [W8A0] 2-2
                                                                                     8. Valve Clearance


  (7) Place suitable container under the vehicle.       (5) Remove the two bolts which hold washer
  (8) Lower the vehicle.                                tank, then secure the tank away from working
  (9) Remove the timing belt cover (RH) bolt.           area.




                                       B2M2016                                               H6M0431

  (10) Remove rocker cover bolts, then remove           (6) Disconnect spark plug cords from spark
  rocker cover (RH).                                    plugs (#2 and #4 cylinders).




                                       B2M2017                                               B2M2024

7) When inspecting #2 and #4 cylinders:                 (7) Disconnect blow-by hose form rocker cover.
   (1) Disconnect battery cables, and then
   remove battery and battery carrier.
   (2) Disconnect front window washer motor con-
   nector.
   (3) Disconnect rear gate glass washer motor
   connector.




                                                                                             B2M2025

                                                        (8) Lift-up the vehicle.
                                                        (9) Remove under cover.
                                                        (10) Place suitable container under the vehicle.

                                       S2M0546

  (4) Disconnect rear gate glass washer hose
  from washer motor, then plug connection with a
  suitable cap.




                                                    9
2-2   [W8A0]                        SERVICE PROCEDURE
8. Valve Clearance


  (11) Remove rocker cover bolts, then remove            9) Measure #1 cylinder valve clearance by using
  rocker cover (LH).                                     thickness gauge (A).
