Image preview - the first page of the document
MSA5T0122A27535


>> Download MSA5T0122A27535 documenatation <<

Text preview - extract from the document
2-1   [W10A0]                         SERVICE PROCEDURE
10. Fuel Sub Level Sensor


10. Fuel Sub Level Sensor                                 6) Remove bolts which install fuel sub level sensor
                                                          on fuel tank.
A: REMOVAL AND INSTALLATION
1) Release fuel pressure.
2) Open fuel flap lid, and remove fuel filler cap.




                                                                                                  S2M0152

                                                          7) Remove fuel sub level sensor.

                                         B2M3197

3) Disconnect battery ground cable.




                                                                                                  S2M0153




                                        G6M0095

4) Remove service hole cover.




                                        G2M0863

5) Disconnect connector from fuel sub level
sensor, and disconnect jet pump hose.




                                         S2M0151



                                                     14
                                      SERVICE PROCEDURE                                      [W11A0] 2-1
                                                                                              11. Vent Valve


8) Installation is in the reverse order of removal.        11. Vent Valve
Do the following:
   (1) Install fuel sub level sensor.                      A: REMOVAL AND INSTALLATION
Tightening torque:                                         1) Remove fuel tank.
    T: 4.4
