Image preview - the first page of the document
MSA5T0123A27621


>> Download MSA5T0123A27621 documenatation <<

Text preview - extract from the document
2-7    [W11A0]                         SERVICE         PROCEDURE
11. Intake Air Temperature and Pressure Sensor


7) Select {Engine Control System} in Selection              11. Intake Air Temperature and
Menu.
8) Select {1. Current Data Display & Save} in               Pressure Sensor
Engine Control System Diagnosis.
9) Select {1.12 Data Display} in Data Display
                                                            A: REMOVAL AND INSTALLATION
Menu.                                                       1) Disconnect battery ground cable.
10) Adjust throttle position sensor to the proper
position to match with the following specifications.
Condition: Throttle fully closed
   Throttle opening angle 0.00%
   Throttle sensor voltage 0.50 V




                                                                                                  G6M0095

                                                            2) Disconnect spark plug cord from ignition coil
                                                            and ignitor assembly.




                                                                                                  B2M3495

                                                            3) Disconnect connector from intake air tempera-
                                                            ture and pressure sensor.




                                                                                                  B2M3496




                                                       32
                                      SERVICE PROCEDURE                                    [W12A0] 2-7
                                                                          12. Atmospheric Pressure Sensor


4) Remove intake air temperature and pressure           12. Atmospheric Pressure
sensor.
                                                        Sensor
                                                        A: REMOVAL AND INSTALLATION
                                                        1) Disconnect battery ground cable.




                                         B2M3497

5) Install in the reverse order of removal.
Tightening torque:
    2.0
