Image preview - the first page of the document
MSA5T0124A27703


>> Download MSA5T0124A27703 documenatation <<

Text preview - extract from the document
                                    SERVICE PROCEDURE                                             [W7A2] 3-2
                                                                                                   7. Road Test


7. Road Test                                             2. SHIFT PATTERNS
                                                         Check "kick-down".
A: INSPECTION
                                                         D range: 1st         2nd      3rd      4th
1. GENERAL PRECAUTION
                                                         3 range: 1st      2nd         3rd  4th
Road tests should be conducted to properly diag-
nose the condition of the automatic transmission.        2 range: 2nd  3rd  4th
CAUTION:                                                 1 range: 1st  2nd  3rd  4th
When performing test, do not exceed posted
speed limit.




                                                                                                        G3M0321




                                                    45
3-2   [W7A3]                          SERVICE PROCEDURE
7. Road Test




                                                            G3M0322


3. ENGINE BRAKE OPERATION
Engine brake operation:
    D range  4th gear
    3 range  3rd gear
    2 range  2nd gear
    1 range  1st gear
4. AWD FUNCTION
If "tight-corner braking" occurs when the steering
wheel is fully turned at low speed:
1) Determine the applicable trouble code and
check the corresponding transfer duty solenoid for
improper operation.
2) If the solenoid is operating properly, check
transfer clutch pressure.
3) If oil pressure is normal but "tight-corner brak-
ing" occurs:
Check the transfer control valve for sticking, and
the transfer clutch facing for wear.  and




                                                       46
