Image preview - the first page of the document
>> Download Read Diagnostic Trouble Code (DTC) documenatation <<Text preview - extract from the document READ DIAGNOSTIC TROUBLE CODE (DTC)
AIRBAG SYSTEM (DIAGNOSTICS)
8. Read Diagnostic Trouble 3) Read the DTC by identifying the way airbag
warning light flashes.
Code (DTC) The airbag warning light flashes a code corre-
A: OPERATION sponding to the faulty parts.
1) Turn the ignition switch to ON. The long segment (1.2 sec on) indicates a "ten",
2) Connect the ground terminal to diagnosis con- and the short segment (0.3 sec on) indicates a
nector terminal No. 1 in the instrument panel lower "one".
cover area. NOTE:
