Image preview - the first page of the document
Driver


>> Download Driver's Airbag Module documenatation <<

Text preview - extract from the document
                                  DRIVER'S AIRBAG MODULE
AIRBAG SYSTEM

4. Driver's Airbag Module                              B: INSTALLATION
                                                       Install in the reverse order of removal.
A: REMOVAL
                                                       CAUTION:
CAUTION:                                               Do not allow harness and connectors to inter-
Refer to "CAUTION" in General Description be-          fere or get tangled up with other parts.
fore handing the airbag module.                          Tightening torque:
1) Position the front wheels straight ahead. (After      Refer to "COMPONENT" in "General Descrip-
moving the vehicle more than 5 m (16 ft) with front      tion"
the vehicle moves straight ahead).                     C: INSPECTION
2) Turn the ignition switch to OFF.
                                                       CAUTION:
3) Disconnect the ground cable from battery, and
                                                       Refer to "CAUTION" in General Description be-
wait for at least 20 seconds before starting work.
                                                       fore handing the airbag module.
