Image preview - the first page of the document



>> Download Horn documenatation <<

Text preview - extract from the document

                                                      HORN
COMMUNICATION SYSTEM

3. Horn
A: REMOVAL
1) Disconnect the ground cable from battery.
2) Remove the front fog light assembly (LH).
3) Remove the horn bracket mounting bolt (A).
4) Disconnect the harness connector and remove
the horn assembly (B).

                                 (A)




                           (B)

                                       COM00002

B: INSTALLATION
Install in the reverse order of removal.
C: INSPECTION
With 12 V direct current supplied between horn ter-
minal and case ground, check that the horn sounds
properly.




                                           COM00003




                                                      COM-4
