Image preview - the first page of the document
>> Download Front Door Panel documenatation <<Text preview - extract from the document FRONT DOOR PANEL
EXTERIOR BODY PANELS
4. Front Door Panel 11) Remove the checker bolts.
A: REMOVAL
1) Disconnect the ground cable from battery.
2) Remove the front door trim.
3) Remove the outer mirror assembly.
4) Remove the front sealing cover.
5) Remove the front door glass. EB-00014
6) Remove the front door regulator and motor. 12) Remove the door-side bolts for upper and low-
7) Remove the front door latch assembly.
8) Remove the front outer handle.
9) Remove the front pillar lower trim to disconnect
the connector from body harness.
EB-00015
13) Using the ST, remove the body-side bolts for
upper and lower hinges, and remove door hinges.
ST 925610000 WRENCH
EB-00012
10) Put a wooden block on jack and place jack un-
der door. Support the door with a jack to protect it
ST
from damage.
EB-00016
B: INSTALLATION
1) Install in the reverse order of removal.
2) Apply grease to the sliding area of door hinges.
Tightening torque:
Refer to COMPONENT in General Descrip-
EB-00013 tion.
When supporting the door with a jack, be careful
not to deform the door hinges while working.
EB-11
FRONT DOOR PANEL
EXTERIOR BODY PANELS
C: ADJUSTMENT
1) Using the ST, loosen the body-side bolts of up-
per and lower hinges to align the position of front
door panel longitudinally and vertically.
ST 925610000 WRENCH
ST
EB-00016
2) Loosen the door-side bolts of upper and lower
hinges to align the position of front door panel ver-
tically and laterally at the front end.
EB-00015
3) Loosen the screw (A) and lightly tap striker (B)
using a plastic hammer to adjust striker to align the
position of front door panel vertically and laterally at
the rear end.
CAUTION:
Do not use an impact wrench. Welding area on
the striker nut plate is easily broken.
(A) (B)
EB-00017
EB-12
