Image preview - the first page of the document
Rear Door Panel


>> Download Rear Door Panel documenatation <<

Text preview - extract from the document
                                        REAR DOOR PANEL
EXTERIOR BODY PANELS

6. Rear Door Panel                                     11) Remove the checker bolts.

A: REMOVAL
1) Disconnect the ground cable from battery.
2) Remove the rear door trim.
3) Remove the rear sealing cover.
4) Remove the rear door glass.
5) Remove the rear door regulator and motor as-
sembly.                                12) Remove the door-side bolts for upper and low-
6) Remove the rear door latch assembly.
7) Remove the rear outer handle.
8) Remove the center pillar lower trim.
9) Remove the seatbelt bracket and blind plug.
Disconnect the connector of door harness and re-
move the door hinge nut.


                                                                                              EB-00015

                                                       13) Using the ST, remove the body-side bolts for
                                                       upper and lower hinges, and remove door hinges.
                                                       ST 925610000        WRENCH
                                                       B: INSTALLATION
                                                       1) Install in the reverse order of removal.
                                                       2) Apply grease to the sliding area of door hinges.
                                        EB-00019
                                                       Tightening torque:
10) Put a wooden block on the jack and place the         Refer to COMPONENT in General Descrip-
jack under the door. Support the door with the jack      tion.
                                                       C: ADJUSTMENT
                                                       1) Using the ST, loosen the body-side bolts of up-
                                                       per and lower hinges to align the position of rear
                                                       door panel longitudinally and vertically.
                                                       ST 925610000         WRENCH




                                        EB-00013

NOTE:                                                                                    ST
When supporting the door with a jack, be careful
not to deform the door hinges while working.

                                                                                              EB-00016




                                                   EB-14
                                           REAR DOOR PANEL
                                                             EXTERIOR BODY PANELS

2) Loosen the door-side bolts of upper and lower
hinges to align the position of rear door panel verti-
cally and laterally at front-end.




                                          EB-00015

3) Loosen the screw (A) and lightly tap striker (B)
using plastic hammer to adjust striker to align the
position of rear door panel vertically and laterally at
the rear end.
CAUTION:
Do not use an impact wrench. The welding area
on the striker nut plate is easily broken.


                  (A)       (B)




                                          EB-00017




                                                     EB-15
