Image preview - the first page of the document
Roof Trim


>> Download Roof Trim documenatation <<

Text preview - extract from the document
                                                 ROOF TRIM
EXTERIOR/INTERIOR TRIM

20.Roof Trim                                             8) Remove the clips, and then remove the roof trim.

A: REMOVAL
CAUTION:
When removing the clip, use great care not to
damage the roof trim.
1) Disconnect the ground cable from battery.
2) Remove the over head console. (Sunroof model)

3) Remove the room light.                                                                                     EI-00077
4) Remove the sun visor and hook or both sides.
                     B: INSTALLATION
5) Remove the assist grip cap to remove assist grip      Install in the reverse order of removal.
(A).


                     (A)




                                          EI-00075

6) Remove the upper inner trim.
7) Remove the rear quarter upper trim shown in the
figure.
   (1) Remove the rear rail trim (A).
   (2) Remove the rear quarter upper trim (B) of
   both sides.


                                    (A)




      (B)

       : (C)                              EI-00076

      (C) Clip




                                                     EI-44
