Image preview - the first page of the document
Rear Quarter Trim


>> Download Rear Quarter Trim documenatation <<

Text preview - extract from the document
                                    REAR QUARTER TRIM
EXTERIOR/INTERIOR TRIM

18.Rear Quarter Trim                                   B: INSTALLATION
                                                       Install in the reverse order of removal.
A: REMOVAL
1) Remove the rear seat.                                         Be sure to securely hook pawls of inner trim
2) Remove the side sill rear cover.                    panel to body flange.
3) Remove the rear rail trim (A).                      NOTE:
4) Remove the strut cap.                               When installing the rear quarter upper trim, be sure
5) Remove the shoulder anchor of rear seat belt.       to set the rear molding as shown in the figure.
6) Loosen the screws and clips to remove rear
quarter upper trim (B).                                             (A)                        (B)
7) Remove the rear skirt trim (C).
8) Loosen the screws and clips to remove rear                                            (C)
quarter lower trim (D).
                                                                      (D)

                                                                                               (E)

                                  (A)

                                                                            (F)
                                                                                                     EI-00106

                                                              (A)   Outside
                                                              (B)   Inside
      (B)                                                     (C)   Molding
                                                              (D)   Weatherstrip
                                                              (E)   Trim
                                                              (F)   Body
                                         (C)

      (D)




        : (E)    : (F)
                                        EI-00073

      (E) Clip
      (F) Hook




                                                   EI-42
