Image preview - the first page of the document
Radio Body


>> Download Radio Body documenatation <<

Text preview - extract from the document
                                                 RADIO BODY
                                                                                                  ENTERTAINMENT

4. Radio Body                                             5) Insert the flat tip screwdriver to the position (A)
                                                          and release the claw with pulling out the lower por-
A: REMOVAL                                                tion of center console panel.
1) Disconnect the ground cable from battery.              CAUTION:
2) Remove the front cover.                                       portion except for indicated in the figure. The
3) Apply the thick protective tape (A) to instrument      instrument panel may be damaged.
panel pad to protect the surface of it.
NOTE:
Also apply the protective tape to the deep inside                (A)                                        (A)
portion between center console panel and instru-
ment panel pad.




                                                                                                           EI-00732

          (A)                                                    (A) Inserting position of flat tip screwdriver

                                                          6) Disconnect the connector.
                                                          7) Remove the fitting screws, and slightly pull out
                                            EI-00731
                                                          the radio from center console.
4) Loosen the screws.                                     8) Disconnect the harness connectors and antenna
                                                          feeder cord.
    (C)                                        (C)
                                                          B: INSTALLATION
                                                          Install in the reverse order of removal.

                        (B)




                                      (A)
                (A)
                                            EI-00728

       (A) Screw
       (B) Clip
       (C) Claw




                                                       ET-5
