Image preview - the first page of the document
Control Unit


>> Download Control Unit documenatation <<

Text preview - extract from the document
                                                              CONTROL UNIT
                                                                              HVAC SYSTEM (HEATER, VENTILATOR AND A/C)

10.Control Unit                                                           6) Insert the flat tip screwdriver to the position (A)
                                                                          and release the claw with pulling out the lower por-
A: REMOVAL                                                                tion of center console panel.
1) Disconnect the ground cable from battery.                              CAUTION:
2) In case of manual A/C, remove the mode cable                           Do not insert the flat tip screwdriver into any
and air-mix cable from links of heater unit.                              portion except for indicated in the figure. The
3) Remove the console front cover.                                        instrument panel may be damaged.


                                                                                 (A)                                        (A)



                                         (A)
                      (A)


                                               (A)
                            (A)

                                  (A)                      EI-00726
                                                                                                                           EI-00732

       (A) Hook
                                                                                 (A) Inserting position of flat tip screwdriver
4) Apply the thick protective tape (A) to instrument                      7) Loosen the screws on rear side of center con-
panel pad to protect the surface of it.                                   sole panel, and then remove the control unit.
NOTE:
Also apply the protective tape to the deep inside
                                                                          B: INSTALLATION
portion between center console panel and instru-                          Install in the reverse order of removal.
ment panel pad.




          (A)




                                                           EI-00731

5) Loosen the screws.

    (C)                                                       (C)




                                        (B)




                                                     (A)
                (A)
                                                           EI-00728

       (A) Screw
       (B) Clip
       (C) Claw




                                                                      AC-29
