Image preview - the first page of the document
Evaporator


>> Download Evaporator documenatation <<

Text preview - extract from the document
                                                EVAPORATOR
HVAC SYSTEM (HEATER, VENTILATOR AND A/C)

15.Evaporator
A: REMOVAL
1) Disconnect the refrigerant recovery & toe board
area A/C pipe.
2) Remove the glove box.
3) Remove lower motor unit assembly.
4) Loosen the screws and remove evaporator cov-
er.




                                           AC-00867

5) Remove the A/C pipes in unit.
6) Rotate the upper part of evaporator tilt toward
the front vehicle and the lower part tilt toward the in-
terior, respectively. Then pull out the heater case to
the left side.
7) Loosen the two bolts to remove expansion valve.




                                           AC-00868

CAUTION:
If the evaporator is replaced, add appropriate
amount of compressor oil to evaporator.
B: INSTALLATION
1) Install in the reverse order of removal.
NOTE:
Replace the o-ring for refrigerant recovery & toe
board area air conditioner pipe with a new one, and
then apply compressor oil.




                                                      AC-34
