Image preview - the first page of the document
Relay and Fuse


>> Download Relay and Fuse documenatation <<

Text preview - extract from the document
                                           RELAY AND FUSE
HVAC SYSTEM (HEATER, VENTILATOR AND A/C)

17.Relay and Fuse                                          B: INSPECTION
A: LOCATION

                                                                                              2
                                                                                                    5
                                                                                                        3




           (2)                                                                        4
                                                                                          1

           (3)


             (1)
                                                                                          4
           (4)                                                                 3
                                                                                          5

           (5)                                                                 1          2



           (6)

                   (7)                                                                             AC-00093

                                         AC-00834
                                                           (1) -- (2): Continuity exists.
                                                           (3) -- (4): Continuity exists.
     (1) Main fuse box (M/B)                               (3) -- (5): No continuity.
     (2) Main fan relay                                    While applying battery voltage to the terminal be-
     (3) Sub fan relay                                     tween (1) and (2), check continuity between (3) and
     (4) A/C relay
                                                           (5).
     (5) Fan mode relay
                                                           If no continuity exists, replace the relay with a new
                                                           one.
     (6) Main fan 20 A (Non-turbo model), 30A (Turbo
         model) fuse
     (7) Sub fan 20 A (Non-turbo model), 30A (Turbo
         model) fuse




                                                       AC-36
