Image preview - the first page of the document
Security Horn


>> Download Security Horn documenatation <<

Text preview - extract from the document
                                              SECURITY HORN
                                                              SECURITY AND LOCKS

21.Security Horn
A: REMOVAL
1) Disconnect the ground cable from battery.
2) Remove the nuts and then detach the security
horn while disconnecting the connector.




                                           SL-00042

B: INSTALLATION
Install in the reverse order of removal.
C: INSPECTION
Connect the battery to the security horn terminal
and case ground and make sure the horn sounds
properly.




                         (A)
                                           SL-00217

       (A) Battery

If NG, replace the security horn.




                                                      SL-43
