Image preview - the first page of the document
Security Horn Relay


>> Download Security Horn Relay documenatation <<

Text preview - extract from the document
                                          SECURITY HORN RELAY
SECURITY AND LOCKS

22.Security Horn Relay
A: REMOVAL
1) Disconnect the ground cable from battery.
2) Remove the mounting bolt and detach the secu-
rity horn relay (near the fuse box).




                                             SL-00044

B: INSTALLATION
Install in the reverse order of removal.
C: INSPECTION
Measure the security horn relay resistance be-
tween terminals (indicated in the table below) when
connecting terminal No. 4 to battery positive termi-
nal and terminal No. 1 to battery ground terminal.
     Current         Terminal No.            Standard
      Flow                                 Less than 1
                       2 and 3
     No flow                              More than 1 M




                                    (A)




                                             SL-00218

       (A) Battery

If NG, replace the security horn relay.




                                                          SL-44
