                                    AIR CLEANER ELEMENT
                                                                     PERIODIC MAINTENANCE SERVICES

10.Air Cleaner Element                                 2) Remove the air cleaner.

A: REMOVAL
1. NON-TURBO MODEL
1) Remove the air intake duct from air cleaner
case.
2) Remove the bolt (A) which installs air cleaner
case to stays.
3) Remove the clip (B) above the air cleaner case.

                                       (A)   (B)                                                  PM-00098
                             (B)
          (B)                                          B: INSTALLATION
                                                       1. NON-TURBO MODEL
                                                       Install in the reverse order of removal.
                                                       CAUTION:
                                                       Fasten with a clip after inserting the lower tab
                                                       of the case.
                                       IN-00239
                                                       2. TURBO MODEL
4) Remove the air cleaner.
                                                       Install in the reverse order of removal.
                                                       CAUTION:
                                                       Align the protruding portion of air cleaner up-
                                                       per cover with holes of air cleaner lower case,
                                                       then secure upper cover to case.




                                     PM-00087

2. TURBO MODEL
1) Remove the clip (B) above the air cleaner case.

                (B)                                                                               PM-00100




                                      PM-00099




                                                   PM-17
