Image preview - the first page of the document
>> Download Diagnostic Trouble Code (DTC) Detecting Criteria documenatation <<Text preview - extract from the document
2. Spark Plug 5) Remove the spark plugs with the spark plug
All spark plugs installed on an engine, must be
of the same heat range.
1. RH SIDE
1) Disconnect the ground cable from battery.
2. LH SIDE
1) Disconnect the battery cables, and then remove
the battery and battery carrier.
2) Remove the air cleaner lower case.
3) Disconnect the connector from ignition coil.
2) Disconnect the washer motor connector.
4) Remove the ignition coil.
3) Disconnect the rear window glass washer hose
from washer motor, then plug connection with a
4) Remove the two bolts which hold washer tank,
then take the tank away from working area.
5) Disconnect the connector from ignition coil. 2. LH SIDE
Install in the reverse order of removal.
Tightening torque (Spark plug):
