Image preview - the first page of the document



>> Download Drain Valve documenatation <<

Text preview - extract from the document

                                              DRAIN VALVE
                                                 EMISSION CONTROL (AUX. EMISSION CONTROL DEVICES)

16.Drain Valve                                         6) Remove the bolt which installs the drain valve
                                                       and drain valve brackets on body, and remove
A: REMOVAL                                             them as a unit.
1) Disconnect the ground cable from battery.




                                                                                            EC-00060
                                     FU-00009
                                                       7) Disconnect the evaporation hoses from drain
2) Lift-up the vehicle.                                valve.
3) Remove the canister.                                     valve.
4) Disconnect the connector from drain valve.



                                                                                    (A)
                                                               (B)




                                                                                            EC-00061
                                      EC-00059
                                                             (A) Drain filter
5) Disconnect the evaporation hoses (A) from joint
                                                             (B) Drain valve
pipes.




                                        (A)




                                      EC-00249




                                          EC(H4DOTC)-19
                                                DRAIN VALVE
EMISSION CONTROL (AUX. EMISSION CONTROL DEVICES)

B: INSTALLATION
Install in the reverse order of removal.
Tightening torque:
  18 N
