Image preview - the first page of the document
>> Download PCV Hose Assembly documenatation <<Text preview - extract from the document PCV HOSE ASSEMBLY
EMISSION CONTROL (AUX. EMISSION CONTROL DEVICES)
17.PCV Hose Assembly
A: REMOVAL
CAUTION:
Removal is not allowed except for the damage
of PCV hose, diagnosis connector and PCV
valve.
1) Remove the intake manifold.
2) Clip the protrusion of clamp after aligning the
concave portion of ST with protrusion of clamp, and
then unlock the lock.
3) Remove the PCV hose assembly.
ST 18353AA000 CLAMP PLIERS
LU-00242
B: INSTALLATION
NOTE:
Replace the clamp with a new one.
1) Install the PCV hose assembly, and then lock
the clamp with protrusion of clamp clipped by pli-
ers.
ST 18353AA000 CLAMP PLIERS
LU-00243
2) Install the intake manifold.
EC(H4DOTC)-21
PCV HOSE ASSEMBLY
EMISSION CONTROL (AUX. EMISSION CONTROL DEVICES)
EC(H4DOTC)-22
