Image preview - the first page of the document
Pressure Control Solenoid Valve


>> Download Pressure Control Solenoid Valve documenatation <<

Text preview - extract from the document
                        PRESSURE CONTROL SOLENOID VALVE
                                                 EMISSION CONTROL (AUX. EMISSION CONTROL DEVICES)

12.Pressure Control Solenoid                           7) Remove the pressure control solenoid valve
                                                       from bracket.
   Valve
A: REMOVAL
1) Set the vehicle on a lift.
2) Disconnect the ground cable from battery.




                                                                                           EC-00231

                                                       8) Disconnect the two evaporation hoses from
                                                       pressure control solenoid valve.

                                      FU-00009

3) Lift-up the vehicle.
4) Remove the canister.
5) Remove the bolt which installs pressure control
solenoid valve holding bracket on body.


                                                                                           EC-00230

                                                       9) Disconnect the vacuum hose from pressure con-
                                                       trol solenoid valve.




                                      EC-00232

6) Disconnect the connector from pressure control
solenoid valve.


                                                                                            EC-00058




                                      EC-00229




                                          EC(H4DOTC)-13
                          PRESSURE CONTROL SOLENOID VALVE
EMISSION CONTROL (AUX. EMISSION CONTROL DEVICES)

B: INSTALLATION
Install in the reverse order of removal.
Tightening torque:
  17.6 N
