Image preview - the first page of the document
Front Exhaust Pipe


>> Download Front Exhaust Pipe documenatation <<

Text preview - extract from the document
                                      FRONT EXHAUST PIPE
EXHAUST

2. Front Exhaust Pipe
A: REMOVAL
1) Disconnect the ground cable from battery.




                                                                                                  EX-00005

                                                      7) Remove the front exhaust pipe assembly.
                                                      8) Remove the covers from exhaust manifold and
                                                      front exhaust pipe.
                                      FU-00009
                                                      9) Separate the front exhaust pipe from exhaust
2) Remove the front oxygen (A/F) sensor.
3) Remove the under cover.
4) Remove the lower exhaust manifold cover (RH)
and the lower exhaust manifold cover (LH).




                                                                                                  EX-00245

                                                      B: INSTALLATION
                                                      NOTE:
                                                      Replace the gaskets with new ones.
                                       EX-00246       1) Assemble the front exhaust pipe and exhaust
5) Remove the nuts which hold front exhaust pipe      manifolds.
assembly to turbocharger joint pipe.                  Tightening torque:
6) While holding the front exhaust pipe assembly        35 N
