Image preview - the first page of the document
Joint Pipe


>> Download Joint Pipe documenatation <<

Text preview - extract from the document
                                                JOINT PIPE
EXHAUST

4. Joint Pipe                                         6) Remove the nuts which hold front exhaust man-
                                                      ifold to joint pipe.
A: REMOVAL
1) Disconnect the ground cable from battery.




                                                                                                 EX-00018

                                                      7) Remove the center exhaust pipe.
connector.                                            8) Remove       the     turbocharger.
                                                      9) Take off the joint pipe in the upward direction.
                                                      B: INSTALLATION
                                                      Install in the reverse order of removal.
                                                      Tightening torque:
                                                        T: 35 N
