Image preview - the first page of the document
Exhaust Temperature Sensor


>> Download Exhaust Temperature Sensor documenatation <<

Text preview - extract from the document
                            EXHAUST TEMPERATURE SENSOR
                                                                     FUEL INJECTION (FUEL SYSTEMS)

16.Exhaust Temperature Sensor                        2) Install the exhaust temperature sensor.
                                                     NOTE:
A: REMOVAL                                           Align the harness (A) of exhaust temperature sen-
1) Disconnect the ground cable from battery.         sor to the marking (B) of joint pipe, and tighten the
                                                     screws.
                                                     Tightening torque:
                                                       21 N
