Image preview - the first page of the document



>> Download Intercooler documenatation <<

Text preview - extract from the document

                                           INTERCOOLER
INTAKE (INDUCTION)

5. Intercooler
A: REMOVAL
1) Disconnect the PCV hose from PCV pipe.




                                                                                          IN-00015

                                                   5) Loosen the clamp (A) which connects turbo-
                                                   charger and intercooler duct.
                                                   6) Loosen the clamp (B) which connects throttle
                                       IN-00011
                                                   body and intercooler.
2) Remove the PCV pipe from intercooler.


                                                                             (B)
                                                            (A)




                                                                                          IN-00016
                                       IN-00012
                                                   7) Disconnect the intercooler duct from turbocharg-
3) Disconnect the hose from air by-pass valve.     er.
                                                   8) Remove the intercooler from throttle body.




                                       IN-00013

4) Remove the bolts which secure intercooler to
bracket.




                                       IN-00014




                                           IN(H4DOTC)-10
                                               INTERCOOLER
                                                                                       INTAKE (INDUCTION)

B: INSTALLATION                                        3) Separate the ducts.
Install in the reverse order of removal.
Tightening torque:
  16 N
