Image preview - the first page of the document
Cylinder Block


>> Download Cylinder Block documenatation <<

Text preview - extract from the document
                                               CYLINDER BLOCK
                                                                                                      MECHANICAL

21.Cylinder Block                                       12) Remove the bolts (c) and (f) to remove cylinder
                                                        head.
A: REMOVAL
                                                                           (c)       (a)              (f)
NOTE:
Before conducting this procedure, drain the engine
oil completely if applicable.
                                                               (A)
1) Remove the intake manifold.
2) Remove the V-belt.
3) Remove the crank pulley.                                             (e)           (b)        (d)
                                                                                                        ME-00309
4) Remove the timing belt cover.                       (A) Front
5) Remove the timing belt assembly.                                                    NOTE:
6) Remove the cam sprocket.                              and cylinder block.
7) Remove the crank sprocket.                     15) Remove the clutch housing cover. (MT model)
8) Remove the generator and A/C compressor with         16) Remove the flywheel (MT model) or drive plate
their brackets.                                         (AT model).
9) Disconnect the PCV hose and remove the rock-         Using the ST, lock the crankshaft.
er cover.
