Image preview - the first page of the document
>> Download Compulsory Valve Operation Check Mode documenatation <<Text preview - extract from the document COMPULSORY VALVE OPERATION CHECK MODE
ENGINE (DIAGNOSTICS)
15.Compulsory Valve Operation (1) Data link connector is located in the lower
portion of instrument panel (on driver's side).
Check Mode
A: OPERATION
1) Prepare the Subaru Select Monitor kit.
ME-00325
(2) Connect the diagnosis cable to data link
connector.
CAUTION:
Do not connect scan tools except for Subaru
EN-00038
Select Monitor and OBD-II general scan tool.
2) Connect the diagnosis cable to Subaru Select 6) Turn the ignition switch to ON (engine OFF) and
Monitor. Subaru Select Monitor switch to ON.
3) Insert the cartridge into Subaru Select Monitor.
EN-00040
(A) Power switch
EN-00039
7) On
