Image preview - the first page of the document



>> Download Oil Pan and Strainer documenatation <<

Text preview - extract from the document

                                    OIL PAN AND STRAINER
LUBRICATION

5. Oil Pan and Strainer                               8) Remove the pitching stopper.

A: REMOVAL
1) Set the vehicle on lift arms.
2) Remove the front wheels.
3) Disconnect the ground cable from battery.




                                                                                           ME-00213

                                                      9) Remove the radiator upper brackets.



                                      FU-00009

4) Remove the air intake duct and air cleaner case.
(Non-turbo model)
5) Disconnect the connector from mass air flow
sensor. (Turbo model)
                                                                                           LU-00049

                                                      10) Support the engine with a lifting device and
                                                      wire ropes.




                                       LU-00026

6) Remove the air intake boot and air cleaner upper
cover. (Turbo model)
                                                                                           LU-00028

                                                      11) Lift-up the vehicle.
                                                      CAUTION:
                                                      When lifting up the vehicle, rise up the wire
                                                      rope together.
                                                      12) Remove the under cover.



                                       LU-00070

7) Remove the intercooler (Turbo model)




                                             LU(H4SO)-18
                                     OIL PAN AND STRAINER
                                                                                      LUBRICATION

13) Drain the engine oil.                              18) Remove the oil strainer.
Set a container under the vehicle, and remove the
drain plug from oil pan.




                                       (A)



                                         (B)
                                                                                       LU-00032

                                                       19) Remove the baffle plate.
                                        LU-00050

       (A) Gasket
       (B) Drain plug

14) Remove the front and center exhaust pipes.
(Non-turbo model)
15) Remove the nuts which install front cushion
rubber onto front crossmember.
                                                                                       LU-00033




                                        LU-00030

16) Remove the bolts which install oil pan on cylin-
der block while raising up engine.
17) Insert the oil pan cutter blade between the cyl-
inder block-to-oil pan clearance.
CAUTION:
Do not use a screwdriver or similar tool in place
of oil pan cutter.




                                        LU-00051




                                               LU(H4SO)-19
                                         OIL PAN AND STRAINER
LUBRICATION

B: INSTALLATION                                          4) Apply liquid gasket to the mating surfaces and
                                                         install oil pan.
CAUTION:
Before installing the oil pan, clean sealant from        Liquid gasket:
oil pan and engine block.                                  Parts No. 004403007
1) Check the seal (A) is securely installed in baffle      THREE BOND 1215 or equivalent
plate in the direction as shown in the figure. (Non-
turbo model)

                (A)




                                                                                                 LU-00034

                                                         5) Tighten the bolts which install the oil pan onto
                                            LU-00052     engine block.
2) Install the baffle plate.                             Tightening torque:
Tightening torque:                                         5 N
