Image preview - the first page of the document
Generator


>> Download Generator documenatation <<

Text preview - extract from the document
                                            GENERATOR
                                                                     STARTING/CHARGING SYSTEMS

3. Generator                                       B: INSTALLATION
                                                   Install in the reverse order of removal.
A: REMOVAL
1) Disconnect the ground cable from battery.       CAUTION:
                                                   Check and adjust the V-belt tension.




                                     FU-00009

2) Disconnect the connector and terminal from                                                 SC-00032
generator.
                                                   C: DISASSEMBLY
                                                   1) Remove the four through-bolts.




                                      SC-00029

3) Remove the V-belt cover.
                                                                                              SC-00078

                                                   2) Heat the portion (A) of rear cover to 50
