Image preview - the first page of the document
>> Download Front Differential Assembly documenatation <<Text preview - extract from the document FRONT DIFFERENTIAL ASSEMBLY
MANUAL TRANSMISSION AND DIFFERENTIAL
18.Front Differential Assembly B: INSTALLATION
1) Insert the bearing outer race to transmission
A: REMOVAL case.
1) Remove the manual transmission assembly
from vehicle. Apply the transmission gear oil to outer surface of
2) Remove the transfer case with extension case bearing outer race.
assembly. ST 499787000 WRENCH ASSY
3) Remove the transmission case. NOTE:
4) Remove the drive pinion shaft assembly.
