Image preview - the first page of the document
ATF Cooler Pipe and Hose


>> Download ATF Cooler Pipe and Hose documenatation <<

Text preview - extract from the document
                                  ATF COOLER PIPE AND HOSE
                                                                                   AUTOMATIC TRANSMISSION

24.ATF Cooler Pipe and Hose                              7) Remove ATF cooler pipe from frame.

A: REMOVAL
1) Set the vehicle on a lift.
2) Remove battery and washer tank.
3) Lift-up the vehicle.
4) Remove the under cover.
5) Disconnect ATF cooler hose from radiator.
NOTE:
