Image preview - the first page of the document
MSA5TCD00L16045


>> Download MSA5TCD00L16045 documenatation <<

Text preview - extract from the document
                                        SERVICE PROCEDURE                                          [W7A1] 6-2
                                                                                        7. Rear Window Defogger


7. Rear Window Defogger                                      4) When tester indicates 12 volts when its probe
                                                             reaches point "A", a broken circuit occurs between
A: INSPECTION                                                point "A" and the negative terminal. Slowly move
                                                             tester probe toward the negative terminal while
1. HEAT WIRES                                                contacting it on heat wire to locate point where
1) Start the engine so that battery is being                 tester indication changes abruptly (0 volts). This is
charged.                                                     the point where a broken circuit occurs.
2) Turn defogger switch ON.                                  When tester indicates 0 volts when its probe
3) Check each heat wire at its center position for           reaches point "A", a broken circuit occurs between
discontinuity by setting direct current voltmeter.           point "A" and the positive terminal. Locate a point
                                                             where tester indication changes abruptly (12 volts)
NOTE:                                                        while slowly moving tester probe toward the posi-
