Image preview - the first page of the document

>> Download MSA5TCD00L16049 documenatation <<

Text preview - extract from the document
                                       SERVICE PROCEDURE                                          [W11A2] 6-2
                                                                                              11. Front Fog Light

10. Dome/Rear Reading Lights                                 11. Front Fog Light
NOTE:                                                        1. EXCEPT OUTBACK
While sitting in the vehicle, be sure to touch the
metal frame of the vehicle to allow all static elec-         1) Lower the front of the mudguard just enough to
tricity to be discharged prior to handling the dome          facilitate subsequent procedures.
light and the replacement dome light.                        2) Disconnect connector.
                                                             3) Remove bolts and then remove front fog light.
1) Disconnect GND cable from battery.
2) Remove dome light lens by inserting a small flat
tipped screwdriver into center slot of the front face
of the lens and press downward, causing the lens
to bow and disengage from the mounting tabs.


                                                             4) Installation is in the reverse order of removal.
                                                             2. OUTBACK
                                                             1) Turn stone guard counterclockwise and then
3) Remove screws and then detach dome light                  remove stone guard.
while disconnecting connectors.
Take care not to touch the circuit board.


                                                             2) Remove bolts.

4) Installation is in the reverse order of removal.
