Image preview - the first page of the document
MSA5TCD00L17548


>> Download MSA5TCD00L17548 documenatation <<

Text preview - extract from the document
                                    SERVICE PROCEDURE                                      [W14A2] 4-4
                                                                                          14. ABS Sensor


14. ABS Sensor                                           2. REAR ABS SENSOR
                                                         1) Disconnect battery ground cable.
A: REMOVAL                                               2) Lift-up the vehicle.
1. FRONT ABS SENSOR                                      3) Remove fuel tank cover.
1) Disconnect battery ground cable.
2) Disconnect front ABS sensor connector located
next to front strut mounting house in engine com-
partment.
3) Remove bolts which secure sensor harness to
strut.




                                                                                               B4M1760

                                                         4) Disconnect rear ABS sensor connector.




                                      B4M1442A

4) Remove bolts which secure sensor harness to
body.



                                                                                               B2M3184

                                                         5) Remove rear sensor harness from clip on body
                                                         side.




                                      B4M1728A

5) Remove bolts which secure front ABS sensor to
housing, and remove front ABS sensor.
CAUTION:
