Image preview - the first page of the document
MSA5TCD00L18191


>> Download MSA5TCD00L18191 documenatation <<

Text preview - extract from the document
                            LEGACY (W2260BE_SGML Complete)



3-2      [M4A0]                     MECHANISM AND FUNCTION
4. 2-4 Brake


4. 2-4 Brake
A: CONSTRUCTION
The 2-4 brake is composed of a 2-4 brake piston, spring retainer, pressure plate, drive plates and
driven plates.
This clutch operates with hydraulic pressure from the transmission control valve to fix the front sun
gear when the 2nd gear is selected in D, 3 or 2 range, or when the 4th gear is selected in D range.




                                                                                              B3H0895A



      (1) Leaf spring                                         (8) Spring retainer
      (2) Snap ring                                           (9) 2-4 brake piston
      (3) Retaining plate                                    (10) Lathe cut seal ring
      (4) Drive plate                                        (11) Lathe cut seal ring
      (5) Driven plate                                       (12) 2-4 brake piston seal
      (6) Pressure rear plate                                (13) 2-4 brake piston retainer
      (7) Snap ring
