MSA5TCD00L18242


>> Download MSA5TCD00L18242 documenatation <<

Text preview - extract from the document
                          LEGACY (W2260BE_SGML Complete)



4-7      [M4A0]                   MECHANISM AND FUNCTION
4. Receiver Drier


4. Receiver Drier
A: MECHANISM
The amount of refrigerant circulating varies with the heat load changes. The receiver drier supplies
the amount of refrigerant necessary for the cycle according to such changes.
1) It removes bubbles from the condensed refrigerant so that only liquid refrigerant may be deliv-
ered to the expansion valve. (If bubbles are present, the refrigerant passing through the expansion
valve varies in quantity, temperature, and pressure, resulting in insufficient cooling.)
2) It removes moisture from the refrigerant.
3) It removes foreign substance from the refrigerant.
The receiver-drier consists of a strainer to remove foreign substance, desiccant to absorb mois-
ture from refrigerant.




                                                                                          B4H0171C

      (1) Head block
