Image preview - the first page of the document
MSA5TCD00L18855


>> Download MSA5TCD00L18855 documenatation <<

Text preview - extract from the document
2-9     [M100]                        MECHANISM AND FUNCTION
1. General


1. General
The exhaust system consists of a front exhaust pipe catalytic converter(s), a center exhaust pipe,
a rear exhaust pipe and a muffler. The front catalytic converter is located immediately behind the
front exhaust pipe, and the rear catalytic converter is incorporated in the center exhaust pipe.
The exhaust system features an improved sound suppression design; the two branches of the
front exhaust pipe join at a point almost equal in distance from the engine's exhaust ports and the
rear exhaust pipe has a resonance chamber in addition to a large capacity muffler.




                                                                                         B2H3426A


      (1) Front exhaust pipe RH                       (6) Rear catalytic converter
      (2) Front exhaust pipe LH                       (7) Resonance chamber
      (3) Front catalytic converter                   (8) Rear exhaust pipe
      (4) Front oxygen (A/F) sensor                   (9) Muffler
      (5) Center exhaust pipe                        (10) Rear oxygen sensor




                                                2
